Самая дешевая офтальмологическая щелевая

Microscope

Type

Zeiss

Magnification change

Five magnification

5

Eyepiece

12.5x

Total magnification

6x  10x  16x  25x  40x

Field of View

6X: 33mm, 10X: 20mm, 16X: 13mm, 25X: 8mm, 40X :5mm

Range of adjusting the distance of pupil

55 mm-75 mm

Range of adjusting eyepieces

-8D - +8D

Slit width

0mm-14mm

Slit length

1mm-14mm

Diameter of aperture

φ14mm,φ10mm,φ5mm,φ2mm,φ1mm,φ0.2mm

Slit angle

0-180

Filter

Heat absorption, Grey, red free(Green), Cobalt blue

Bulb

LED

Moving

Forward and backward moving

90mm

Left and right moving

100mm

Handle moving

15mm

Up and down moving

30mm

Jaw bracket part

Up and down moving

80mm

Fixation

Red LED

Power

Input voltage

110/220V±10%

Input frequency

50/60Hz

Input power

60VA

Output voltage

Illumination:      DC5V

Safe standard of electric

IEC601-1, type Ⅰof BF Model

Weight and

Dimension

Packing box

720mmx495mmx480mm

Gross weight

25Kg

Net weight

21Kg
