V-REFLEX™ Reflective Material Spandex Fabric RF-HW656030-X1
V-REFLEX™ Silver Color Reflective Spandex Fabric RF-HW656030-X1 Is Intended For The Application On High-Visibility Clothing Such As Occupational Work Wear, Sport Wear, Fashion Apparel, Consumer Garments And Accessories To Enhance The Visibility Of The Wearer During Darkness And Low Light Conditions. The Fabric Will Appear Brilliant White, When Illuminated By Vehicle Headlights, Even When The Wearer Is Situated At The Side Of The Road.
Features
Material: Spandex/ Nylon/ Polyester
Backing Fabric: Stretchable Fabric
Day Time Color: Silver Color
Reflective Color: White
Thickness: 0.4-0.6mm
Weight: 200-300 gsm
Width: 100 cm
Technics: Knited
Distinguished Functions: Breathable, 4-way Stretchable, Retro-reflective
Retro-Reflective Technology: Micro Glass Bead
Type: 1-Side Reflective Stretchable
Retro-Reflective Performance: EN ISO 20471, ANSI 107 Level 2
Certificate: OEKO-TEX Standard 100
High Elasticity, High Reflective Intensity Grade
Offers Excellent Durability And Smooth Hand
4-Way Stretchability
150+ % Elastance of Still Dimension
Physical Performance
V-REFLEXTM Reflective Material - Reflective Spandex Fabric Meet Or Exceed The Following Specifications As Noted. All RA Values Are Over 100 Cd/Lux/M2 Measured At +5.0° Entrance Angle And 0.2° Observation Angle After Tests Are Carried Out According To Following Test Methods
Physical Performance | Test Method |
Retro-Reflectivity (Initial) | ANSI-ISAE 107-2010 Level 2 EN ISO 20471 |
Abrasion: RA >100 | 5000 Cycles (En 530 Method 2) |
Flexing : RA >100 | 7500 Cycles (Iso 7854 Method A) |
Cold Fold : RA >100 | -20° (Iso 4675) |
Temperature Variation : RA >100 | 50 Hours @ 50°C And 20 Hours @ -30°C |
Wash : | Normal Home Wash |
Wet Reflectivity : RA >100 | ANSI-ISAE 107-2010 Level 2 , EN ISO 20471 |
Convective Heat : RA >100 | 10 minutes at 140 oC (285 oF) |
Heat Resistance | 5 minuts at 260 oC (500 oF) (ISO 17493) |
Dry-Cleaning | N/A |
Flame Resistance | N/A |
Retro-reflective Performance
The coefficient of retro-reflection (RA in cd/lux/m2) is measured by methods traceable to either of the following retroreflective intensity testing procedures :
ASTM E809-08 and E810-03 (RA)
CIE 54.2:2001 (R’)
The coefficient of retro-reflection exceed the minimum retro-reflectivity requirements in according to EN 471 and ANSI 107 level 2 as table below.
Observation Angle | Entrance Angle | |||
5° | 20° | 30° | 40° | |
0.2° | 330 | 290 | 180 | 65 |
0.33° | 250 | 200 | 170 | 60 |
1.00° | 25 | 15 | 12 | 10 |
1.50° | 10 | 7 | 5 | 4 |
The initial average RA > 500
Coefficient of reflection (RA in cd/lux/m2) measured at +5.0° entrance angle and 0.20° observation angles on new product is over 500
Product Application
Apparel And Clothing Articles Where Stretch Is Desired, Generally For Comfort And Fit, Such As: Active Wear, Athletic, Aerobic And Exercise Apparel, Belts, Bra Straps And Side Panels, Cycling Jerseys And Shorts, Gloves, Leggings, Bodysuits, Rowing Unisuits, Cross Country Race Suits, Slacks, Miniskirts, Zentai…..
Compression Garments, Such As Foundation Garments, Motion Capture Suits ......
Shaped Garments, Such As Bra Cups, Support Hose, Superhero Outfits, Volleyball Shorts......
Cutting
Die-Cutting Is Recommended, Although It Can Also Be Hand-Cut Or Guillotined.
Note: Use Very Sharp Cutting Knives Only And Cut From The Reflective Side.
Sewing
To Achieve Better Result When Sewing Your Project With Spandex Fabric, Refer To The Following Tips:
To Avoid Skipped Stitches, Use Ball Point Needle (Golden Colored) 90/14 When Sewing
On Stretch Fabrics.
Use Thread For Knits Or A Stretch Stitch.
First, Baste The Pieces Of Fabric Together, And Then Sew Without Stretching The Fabric.
Place Thin Paper Or Stabilizer Material Under The Fabric And Sew It Together With The Fabric.
When You Have Finished Sewing, Tear Off Any Excess Paper.
Decrease The Pressure Of The Presser Foot. (It Is Applied To Models Equipped With The
Function To Adjust The Presser Foot Pressure)
For The Best Results, Sew In Place Using A Lockstitch And With No More Than 12 Stitches Per Inch (2.54 Cm), And Not Less Than 5/64” (2 Mm) From The Edge Of The Reflective Fabric. Recommend For Applying To Light And Medium Weight Fabrics.
