Система управления гравировкой лазерной резки RuiDa RD6332M / RDC6442s/

The RDC6332M hybrid cutting control system is a set of hybrid cutting systems specially developed by Ruida Technology based on the mature RDC6332G control system, combining metal sheet and non-metal cutting processing technology. Based on this controller, metal cutting and non-metal cutting can be realized.

Technical Parameters:
1.Digital laser control signal, differential output, TTL level, 20mA drive capability;
2. The PWM frequency is adjustable from 2.5K to 100K, and the PWM duty cycle is adjustable from 1% to 99%;
3. Analog laser control signal 0 ~ 5V auto-follow adjustment, TTL level, 20mA drive capability, motor control pulse frequency up to 500KHZ;
4, USB maximum transmission rate of 12M, the longest distance of 5 meters;
5. Linear / circular / B-spline interpolation accuracy +/- 0.5 pulse;
6, 4 general-purpose photoelectric isolation OC gate output, maximum 600mA drive capability;
7, 4 universal photoelectric isolation inputs, TTL level;
8.Onboard system encryption control, onboard parameter storage and maximum 256M file storage capacity

Q1. Laser Machine Warranty:

Whole machine with 24 months quality warranty, extra fee is paid if out of date. Any damage to the machine

caused by improper use will be charged.

Q2. Laser Tube Warranty:

Reci laser tube with 10 months warranty; Yongli 260-300W laser tube with 12 months warranty.

Q3.What control system it use ?

A:DSP control system ( RDcam or Leetro for choose).

Q4.Which kind of machine is more suit for me?

A:It is according the material and processing thickness and the working area.

Q5.How to support me if i don't know how to use it?

A:Free training within the warranty by WhatsApp, Skype, Fax, Mail, Wechat, QQ. We also can dispatch our

 technician to customer’s company to provide training and support if customer agree the air ticket and hotel.

Q6.How transport?

A:By sea or by air.
