LTMG 4ton 5ton 6ton 7ton 8ton 4t 5t 6t 7t 8t колесный погрузчик с джойстиком двигателя США и
- Категории: Loaders >>>
- Поставщик: Xiamen,Ltmg,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Features
Specification of LTMG 5 ton wheel loader | ||||||
Operating weight | 17100kg | |||||
Rated load | 5000kg | |||||
Bucket capacity | 3m³ | |||||
Engine model | WEICHAI WD10G220E23 | |||||
Rated power | 162KW | |||||
Rated rotate speed | 2000r/min | |||||
Max torque | 745.3N.m | |||||
Breakout force | 145KN | |||||
Driving speed | ||||||
Forward Ⅰ | 0-11.5 km/h | |||||
Forward Ⅱ | 0-38 km/h | |||||
Reverse Ⅰ | 0-16 km/h | |||||
Grade ability | 28 | |||||
Overall length | 7460mm | |||||
Overall Width | 2870mm | |||||
Overall hight | 3220mm | |||||
Bucket width | 3000mm | |||||
Wheel base | 3200mm | |||||
Track base | 2260mm | |||||
Min. ground clearance | 450mm | |||||
Max. drumping height | 3100mm | |||||
Max. drumping reach | 1310mm | |||||
Transmission | Planet-type | |||||
Raise time | ≤ 6.8s | |||||
Total | ≤ 12.5 | |||||
Tire type | 23.5-25 | |||||
LTMG after sale service
LTMG always treat after-sale service as important as sale. Nowadays more than 50 agents and 21 after sales center around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
