Высокая скорость и более высокая точность обработки XK7136 вертикальный фрезерный станок с

Specification

Unit

XK 7136

X-axis travel

mm

960

Y-axis travel

mm

400

Z-axis travel

mm

500

Table size

mm

1250*360

Distance from spindle nose to table surface

mm

100-600

Spindle center to column guide way surface distance

mm

460

(X/Y/Z) rapid travel

m/min

8/8/8

Cutting feed speed

mm/min

1-5000

ATC type

Arm tool post/Disc tool post

ATC capacity

16/24 PCS

Max. load on table

kg

350

Number of T-solt

3/14/80

Spindle speed

r/min

8000

Spindle servo motor power

kw

5.5

Spindle taper

BT40/BT120

Positioning accuracy

mm

0.0075(standard)   0.005(optional)

Repeatability accuracy

0.005(standard)  0.003(optional)

Weight

kg

2400

Packing dimension

mm

2220*1860*2280
