kydera dmr repeater TR-6000DM & vhf uhf duplexer
Product Images
——————— Product Images ———————
Product Details
——————— Product Details ———————
Main Features:
16 Channel Zone (256 Digital &256 Analog) | Backlight Control |
| Language Selection | Scan |
| 3.5'' big & colorful TFT display | Zone Setting |
| Profile Options | High/Low Power |
| Keytone Control | Display Mode |
Digital Features:
| Group Call | Contact |
| SMS | Call Log |
Analog Features:
| CTCSS | DCS |
Specification:
Model | TR-6000DM | ||
Frequency | UHF | VHF | |
Frequency Range | 400-470MHZ | 136-174MHZ | |
Channel Zone | 16 | ||
Total Channel Capacity (512) | 256 (Analog) | ||
256 (Digital) | |||
Typical RF output | 25-40W | 25-50W | |
Measurement(H*W*D) | 88*483*366mm | ||
Voltage demand | 100-240 VAC ( 13.6 VDC ) | ||
Weight | 14kg | ||
Current consumption: Standby Transmitting | 1.0A (100VAC), 0.5A (240 VAC) 4.0A (100VAC), 1.8A (240 VAC) | ||
Working temperature | -30℃ + 60℃ | ||
Max work cycle | 100% | ||
FCC description | ABZ99FT4025 | ABZ99FT3025 | |
Receiver:
Frequency range | 400-480MHZ | 136-174MHZ | |
Channel Spacing | 12.5kHz /25kHZ | ||
Frequency Stability | (-20℃,+60℃,+25℃) + / -0.5 ppm | ||
Analog Sensitivity | 0.35uV (20 dB SINAD) 0.25uV (12 dB SINAD) 0.2uV (Typical) | ||
Digital Sensitivity (5% BER) | 0.3uV | ||
Intermodulation TIA603C ETS | 75dB 70dB | ||
Adjacent Channel Selectivity | 60dB12.5kHz / 70dB 25kHz | ||
Spurious Rejection TIA603C ETS | 75dB 70dB | 80dB 70dB | |
Audio distortion @ rated audio | 3% ( Typical ) | ||
Hum & Noise | -40dB 12.5kHz / -45dB 25kHz | ||
Audio Response | +1,-3dB | ||
Conducted spurious Emission | -57dBm | ||
Transmitter:
Frequency | 400-470MHZ | 136-174MHZ | |
Channel Spacing | 12.5kHz /25kHZ | ||
Frequency Stability | + / - 1.5ppm (XiR M8260) + / - 0.5ppm (XiR M8268) | ||
RF output | 25-40W | 25-50W | |
Modulation limit | ±-2.5 12.5kHz / ±-5 25kHz | ||
FM Hum & Noise | -40dB 12.5kHz / -45dB 25kHz | ||
Conducted /Radiated Emission | -36dBm<1GHz / -30dBm>1GHz | ||
Adjacent Channel Selectivity | -60dB 12.5kHz / -70dB 25kHz | ||
Audio Response | +1,-3dB | ||
Audio Distortion | 3% | ||
FM Modulation | 12.5kHz: 11K0F3E 25kHz: 16K0F3E | ||
4FSK Digital Modulation | 12.5kHz Data: 7K60FXD 12.5kHz Data & Audio: 7K60FXD | ||
Digital Vocoder | AMBE+2™ | ||
Digital Agreement | ETSI-TS102 361-1 | ||
