Высокое качество механический домкрат путевой рельс

Описание и отзывы

Характеристики

Production Introduction:



Rack up the machine is mainly used for railway track laying and maintenance.In industrial and mining enterprises and the bridge erecting operation is widely used for lifting and supporting the installation of various weights, and equipment.



Application



1. Improve - track jack should be smoothly completed, with a length of 1.5 m steel steel rod inserted into the rocker arm hole, up and down reciprocating throw to the need of hoisting heposition.
2. Slow down - turn slowly drop control handle up to brake position will lever up and down throw, every reciprocating or drop a tooth.
3 drops - pull lever, with leverage vertical impact downhill baseboard end surface, can be a down to the starting

Main Parameter:



Max lifting capacity of the top	Max lifting capacity of foot-hoot	Lifting height	Total height	Foot-hook	NW	Dimensionm
5T	2.5T	160mm	345mm	43mm	17kg	191X130X384 mm
10T	5T	180mm	410mm	45mm	24kg	230X154X418 mm
15T	7.5T	280mm	580mm	60mm	37kg	260X135X590 mm
20T	10T	350mm	680mm	75mm	43kg	280X140X630 mm
