Онлайн 3 фазы система источников бесперебойного питания 60 кВА 80 100 ценам в

UPS capacity: 10~100kva

10 kVA UPS module (CM10)

Configuration: 10 slots

Components: STS module, Monitor module, UPS module, Power distribution

Top or bottom feed

System dimension: 600*800*1600 (W*D*H) mm

Module dimension: 482*465*89 (W*D*H) mm

Battery: optional battery pack

Back up time: according to load capacity

CMS UPS units are non-isolated, industrial level, green UPS, adopting advanced modular power protection concept. CMS Modular architecture can scale power as demand grows or as higher levels of availability are required. CMS UPS is industry-leading efficiency, availability, and performance for small, medium, and large data centers and mission critical environments.

• Rational redundant structure
• UPS module: 10 kVA System: 60KVA/80KVA/100KVA
• Great performance index
• overall efficiency ≥ 95%(AC-AC), inverter efficiency ≥ 98%(DC-AC), THDI ≤ 3%, and input PF ≥ 0.99
• N+X module-level redundancy UPS System
• Multi-level decentralized control technology and Master-slave synchronization in sequency control which result in eliminate system failure bottleneck
• Each module automatically even shares the input and output current, all UPS modules share batteries
• Battery Management Function:
• Battery discharge management, auto-transfer between floating and even charging, temperature compensation
• Space-saving high density design, Rack-based for agility and aesthetics
• Monitor Function
• C/S-Oriented Architecture SICON Software which is available to monitor multiple UPS up   to 600 sets; B/S-Oriented Architecture which is available to check via IE
• Standard configuration
• Manual maintenance bypass, SPD(Class C), RS232, RS485/RS422 Communication ports,       Remote monitor software, day contacts
• Optional configuration
• EPO, Input/output Transformer, Battery Bank, IPDS(Intelligent Power Distribution System)

Small server room, network, bank, security, transportation, broadcast&TV network, HealthCare, Communication, Finance.

                                                                                                                                                                                                                                         Corporate URL: www.sicon-emi.com

Sicon Modular UPS

Full range modular UPS 6-3200kVA, 14 years experience, No.1 market share in China

ERMS online UPS

Rack mount, flexible combine with battery, price competitive with standalone UPS.

DSM online UPS

High frequency, digital technology, IGBT, competitive with Europe brand.

DSP online UPS

Small volume, high power density, competitive with APC.

   Certifications

  Sicon Customers                                                                                                                                                        Sicon Partners





With factory& headquater in China, subsidary in Netnerland and partners in 50 countries worldwide, Sicon is dedicated infour sectors: UPS,  uniterruptible power supply, data center facility, EV charge infrasturecure and ESS energy storage. Over 100pcs innovation patent of these products have been made by Sicon engineers. Technical leading and future driven, Sicon is able to make your business profitable.

   Sicon factory

   Package

1.       About Sicon Technology?

Sicon R&D Staff ratio exceeds 30%, annual investment exceeds 10% of sales. As the core of Sicon, R&D team shoulders crucial responsibilities in research, developing new products, and perfecting existing products. As the power leader, Sicon is dedicated in not only electrical and power electronic technology, but also social responsibility of building a green, sustainable and intelligent world.

........................................................................................................................................................................................................................................

2.       About Quality Control?

We make use of automatic and visual inspection throughout the complete production process. To ensure our ongoing quality, Sicon operations are certified to ISO9001:2001 and ISO14001:2004 standard. All our product solutions carry TLC and CE Certification.

........................................................................................................................................................................................................................................

3.       About Warranty?

The manufacture warrants its products to be free from defects in materials and workmanship for a period of two years from the date of purchase.

 .......................................................................................................................................................................................................................................

4.       About Service?

We promise to react to any service demands within 2 hours, and solve the problem within 48 hours, to satisfy customers with the best perfect service.

........................................................................................................................................................................................................................................

More details at: www.sicon-emi.com
