Качественный клапан из нержавеющей стали DIN

Steel gate valves accoring to: DIN 3352

Steel gate valves: ISO 10434 / ISO 14313

Steel valves: ASME B16.34

Face to face is according to: DIN 3202 F4/F5/F7/F12

Flanges Ends: DIN 2543, DIN 2544, DIN 2545, DIN2546

Butt Welding Ends: DIN

Inspection and Testing: DIN3230 / API 598 / API 6D

Full Port Design

OS&Y,Outside Screw and Yoke

BB,Bolted Bonnet

PSB,Pressure Seal Bonnet

Flexible Wedge, Fully Guided

Choice of Solid or Split Wedge

Size: DN40-DN1200

Pressure: PN6, PN16, PN25, PN40, PN63(64), PN100, PN160, PN250, PN320, PN400

Connection: Flanges,RTJ Flange,Butt Weld,Groove

Material:
Carbon Steel, Forged Steel, Stainless Steel: 1.0619, 1.1138, 1.4308, 1.4408, 1.4306, 1.4404 etc.

Specifical Material:
Duplex Steel, Super Duplex Steel, Inconel: GR4A, GR6A, CY-40, Inconel 600

Operate: Handwheel, Wormgear, Gearbox, Penumatic Actuator, Electric  Actuator, Hydraulic Actuator.

♥We are manufacturer of steel pipe&fittings,

like valve, equal or reducing tee,45deg/90deg/180deg elbow,

CON or ECC reducer,pipe cap ,flange & other steel tube.

♥Feel free to contact us if you have any questions or requirements,we assure of our best attention all the time.
