The DP720 allows the user to unbind themselves from their desk and move freely and efficiently throughout the work environment. When paired with Grandstream’s DP750, the DP720 offers a mobilized VoIP solution for any business or residential user. This mobile DECT handset is the ideal choice for users who are looking to be mobile and have access to essential call control features. Up to 5 DP720 handsets can pair with a single DP750 DECT base station, and each support up to 10 SIP accounts, full HD audio, a 3.5mm headset jack, multi-language support, a speakerphone and more.
Detailed Images
Product Features
DP750
Up to 10 SIP accounts per system; up to 10 lines per handset; up to 5 concurrent calls per DECT system
Supports a range of up to 300 meters outdoors and 50 meters indoors
3-way voice conferencing, full HD audio, integrated PoE
Automated provisioning options include TR-069 and XML config files
TLS and SRTP security encryption technology to protect calls and accounts
Use with Grandstream’s UCM series of IP PBXs for Zero Config provisioning
Offers multiple ring group options, including Circular, Linear, Parallel and Shared modes
DP720
Supported by Grandstream's DP750 DECT Base Station
5 DP720 handsets are supported by each DP750
Supports a range of 300 meters outdoors and 50 meters indoors from the DP750 base station
Supports up to 10 SIP accounts per handset
Full HD audio on both the speakerphone and handset
3.5mm headset jack, 3-way voice conferencing
Automated provisioning options include TR-069 and XML config files
DECT authentication & encryption technology to protect calls and account
Number of Channels: 10 (Europe), 5 (US, Brazil or Japan), 3 (Korea), 8 (Taiwan)
Range: up to 300 meters outdoors and 50 meters indoors
Peripherals
1.8 inch (128x160) color TFT LCD
23 keys including 2 soft keys, 5 navigation/ menu keys, 4 dedicated function keys for SEND, POWER/END, SPEAKERPHONE, MUTE
3-color MWI LED
3.5mm headset jack Removable belt clip
Micro-USB port for alternative charging and non-battery operation
Protocol/Standards
Hearing Aid Compatibility (HAC) compliant
Voice Codecs
G.722 codec for HD audio and G.726 codec for narrow band audio (G.711μ/a-law, G.723.1, G.729A/B, iLBC and OPUS are supported via companion DECT base station DP750), AEC, AGC, Ambient noise reduction
Telephony Features
Hold, transfer, forward, 3-way conference, call park, call pickup, downloadable phonebook, call waiting, call log, auto answer, click-to-dial, flexible dial plan, music on hold
Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC 1A; Micro-USB connection; Rechargeable 800mAh Ni-MH Low Self-Discharge (LSD) AAA batteries (250 hours of standby time and 20 hours of talk time)
Package Content
Handset unit, universal power supply, charger cradle, belt clip, 2 batteries, Quick Start Guide
Dimensions (H x W x D)
Handset: 155 x 50 x 26 mm, charger cradle: 35 x 63.5 x 54 mm
Temperature and Humidity
Operation: -10º to 50ºC (14 to 122ºF); Charging: 0 to 45ºC (32 to 113ºF) Storage: -20º to 60ºC (-4 to 140ºF); Humidity: 10% to 90% non-condensing
Compliance
FCC: Part 15D, 47 CFR 2.1093 & IEEE1528-2013, Part 68, Part 15B CE: EN60950, EN301489-1-6, EN301406, EN50360; EN62209-1 RCM: AS/NZS60950, AS/ACIF S004 ANATEL: #2288-16-9452
Conpany profile
ChuCheng Information Technology Co., Ltd. ,which provides main services in terms of broadband communications and information technology industries, is a research anddevelopment, production, sales, service integration, high-tech enterprises. Our products mainly covers the optical signal transmission and access, signal transmission and access,photoelectric signal conversion and photoelectric signal and so on.
ChuCheng is the agent of well-known international brands such as HUAWEI, ZTE,CISCO, ZYXEL, GRANDSTREAM, etc.The clients include major national telecom carriers, as well as radio and television, electricity, mining and other industry professional net users. We has been actively expanding into foreign markets. The products are exported to Europe,America, Southeast Asia, the Middle East , Japan, Korea and other neighboring countries.
