Заводская цена машина для бетононасоса/дизельный

Описание и отзывы

Характеристики



TECHNICAL DATA
Model No.	DY-HBTS50
Overall dimension (main machine)	4200*1500*1550mm (L*W*H)
Max. Conveying Capacity	30 Cubic meter
Max. Exit Pressure	12Mpa
Main Oil Pump	KAWASAKI
Distribution valve	S Valve
Max. Aggregate Size	≤40mm
Bore Diameter * Diameter	180*1100mm
Pipe Diameter	80mm/100mm/125mm
Engine Power	66KW
Horizontal max. transport distance	200m
Vertical max. transport distance	60m
Control Way	Electric or diesel driven
Other configuration	Can be matched
Machine weight	2400KG

---------------------------------------------------------------------------------------------------------------------------------------------------------------









 Features:
·Advanced with advanced S-tube valve to meet the transportation of fine stone concrete
·S tube valve is equipped with floating wear ring, which automatically compensates for wear and has good sealing performance.
·The glasses plate and cutting ring are made of high-hard wear-resistant alloy material for longer life.
·High export pressure to meet the transportation requirements of high-rise buildings and long-distance construction
·The hydraulic system adopts double-circuit open system, which has fast commutation speed and high efficiency.
·Hydraulic oil cooling adopts advanced air cooling system, no need to connect water source, easy to use
·With anti-pump function to minimize pipe blockage
·Equipped with automatic centralized lubrication system to ensure the service life of rotating parts
·Electrical part is controlled by PLC and has the best control characteristics
·Electric box with wired remote control for easy operation
