Сверхпрочная внедорожная антенна из стекловолокна UHF 6 дБи черного цвета для связи с
- Категории: >>>
- Поставщик: Dongguan,Baiao,Electronics,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Specifications
Factory High Quality VHF/UHF CB Antenna Spring Whip Walkie Talkie with Coaxial Vehicle Mounted :
* Solid fiberglass former with strong and flexible spring & coated with black polyolefin.
* Ease to tune: No need to cup whip to set SWR.
* Installation: This antenna can be mounted by a bracket.
* Strong magnetic base: remains secure on any type of car.
* Custom Cable: 15ft of prewired, RG-58 90% shielded coax with the PL259 (UHF)connector.
Frequency Range | Can be customized from 27MHz to 1.8 GHz |
V.S.W.R | 1.5 : 1 Max |
Gain | 6.5 - 8.5 dBi |
Impedance | 50 Ohm |
Radiation Pattern | Omni-directional |
Polarization | Linear Vertical |
Max Power | 300 W |
Cable | RG-58 |
Connector | UHF / SMA (M) (Optional) |
Size: | Φ55*1200 mm |
Related Products
BIO-C055 | BIO-C872 | BIO-C100 | BIO-C899 |
144/430 MHz (Optional) | 26-28 MHz | 26-28MHz | 26-28MHz |
300 W | 300W | 300W | 300W |
Φ45 * 900 mm | Φ78*790mm | Φ90*1086 mm | Φ78*726 mm |
Baiao Electronics Technology was established in 2008 and has been become one of the leading OEM/ODM manufacturer specialized in telecommunication products and peripherals. Our main products including TV antennas, CB antennas , GSM/3G/4G LTE antennas, Wi-Fi antennas, RF Coaxial cable and other related products.
