Экскаватор для трактора 45-60hp хорошего

Model

 LW-8

 Specification

 Inch

 Metric

 Tractor HP

 45-60HP

 3-point Linkage

Cat-1&2

 Structure Weight

 1280lb

  580kg

 A

 Digging Depth(two foot flat bottom)

 7.38’

 2250mm

 B

 Reach from center line of Swing pivot

 10.5’

 3200mm

 C

 Loading Height(bucket at 60°)

 3.66’

 1930mm

 D

 Transport Height(maximum)

 6.98’

 2130mm

 E

 Extend Height

 10.62'

 3240mm

 F

 Loading Reach(bucket at 60°)

 3.74'

 1140mm

 G

 Transport Overhang

 4'

 1220mm

 H

 Undercut

 1.54'

 470mm

 I

  Bucket Rotation

 180°

 J

 Stabilizer Spread(up position)

  4.3’

 1310mm

 K

 Stabilizer Spread(down position)

 7.67’

 2340mm

 L

 Swing Arc

 180°

M

Bucket width

450mm

N

Bucket cubage

0.052
