5005 5052 6061 7075 T6 алюминиевый стержень 5 мм 9 10 12 15
- Категории: Брусковый алюминий >>>
- Поставщик: Dongguan,Dechuang,Hardware,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
DETAIL SHOW
Real Take
Relevant Property
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | OTHERS | OTHERS | Al |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | — | 0.05 | 0.03 | 0.03 | — | 99.5 |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | — | 0.04 | 0.03 | 0.03 | — | 99.7 |
| 1100 | 0.95 Si + Fe | 0.05-0.20 | 0.05 | — | — | 0.1 | — | 0.05 | 0.15 | 99 | |
| 2024 | 0.5 | 0.5 | 3.8-4.9 | 0.30-0.9 | 1.2-1.8 | 0.1 | 0.25 | 0.15 | 0.05 | 0.15 | Rem. |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | — | — | 0.1 | — | 0.05 | 0.15 | Rem. |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0-1.5 | 0.8-1.3 | — | 0.25 | — | 0.05 | 0.15 | Rem. |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0-1.5 | 0.20-0.6 | 0.1 | 0.25 | 0.1 | 0.05 | 0.15 | Rem. |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50-1.1 | 0.1 | 0.25 | — | 0.05 | 0.15 | Rem. |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | 0.1 | — | 0.05 | 0.15 | Rem. |
| 5252 | 0.08 | 0.1 | 0.1 | 0.1 | 2.2-2.8 | — | 0.05 | — | 0.03 | 0.1 | Rem. |
| 6061 | 0.40-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.05 | 0.15 | Rem. |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-6.1 | 0.2 | 0.05 | 0.15 | Rem. |
| Alloy | Temper | Tensile Strength | Yield Strength | Elongation (%) | Tensile Strength | Yield Strength | |
| (ksi) | (ksi) | 0.01-0.05 in | 0.051-0.125 in | (MPa) | (MPa) | ||
| 1100 | H12 | 16 | 15 | 4 | 12 | 110.3 | 103.4 |
| H14 | 18 | 17 | 3 | 10 | 124.1 | 117.2 | |
| 3003 | H12 | 19 | 18 | 9 | 11 | 131 | 124.1 |
| H14 | 22 | 21 | 3 | 7 | 151.7 | 144.8 | |
| 3004 | H32 | 31 | 25 | 6 | 15 | 213.7 | 172.4 |
| H34 | 35 | 29 | 5 | 10 | 241.3 | 199.9 | |
| 3005 | H12 | 26 | 24 | 5 | 13 | 179.3 | 165.5 |
| H14 | 29 | 28 | 4 | 9 | 199.9 | 193.1 | |
| 5005 | H12 | 20 | 19 | 5 | 9 | 137.9 | 131 |
| H14 | 23 | 22 | 4 | 7 | 158.6 | 151.7 | |
| 5052 | H32 | 33 | 28 | 7 | 10 | 227.5 | 193.1 |
| H34 | 38 | 31 | 6 | 8 | 262 | 213.7 | |
| 5056 | O | 42 | 22 | 23 | 24 | 289.6 | 151.7 |
| H38 | 60 | 50 | 6 | 13 | 413.7 | 344.7 | |
| 6061 | T4 | 35 | 21 | 22 | 24 | 241.3 | 144.8 |
| T6 | 45 | 40 | 12 | 17 | 310.3 | 275.8 | |
| 7075 | O | 33 | 15 | 16 | 18 | 227.5 | 103.4 |
| T6 | 83 | 73 | 11 | 12 | 572.3 | 503.3 | |
| Surface Finish | Definition | Application |
| 2B | Those finished, after cold rolling, by heat treatment, picking or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry,Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treament after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building construction. |
| NO.1 | The surface finished by heat treament and picking or processes corresponding there to after hot rolling. | Chemical tank, pipe. |
Compare
Related Products
Our Company
Dongguan Dechuang Hardware Co.;Ltd
1. Founded in 2003 ,Focused on Metal Raw Material over 15 Years Customized Experience.
2. Fast Delivery Time :3-5 days ( Standard Size ).
3. Mass Stock:5000 M2 Warehouse and 2 Factories.
4. 5 sets of professional equipment to ensure quality
5. Acquired the Certificates of ISO,TUV,ROSH,REACH and Other Relevant Classifications.
Certifications
Product Packaging
