Instructions Pocket Fetal Doppler is a hand-held obstetrical unit, which can be used in hospital, clinic and home for daily self-check by pregnant woman.The device uses color LCD of high resolution to display the fetal heartbeat waveform, and figure out the FHR to help the doctor diagnose in time.It contains components of ultrasonic signal transmitter and receiver, analog signals processing unit, FHR calculating unit, LCD display control unit etc.It also has audio output, and can be connected with earphone or recorder with audio input.
Features: Beautiful shape, portable, easy operation The probe has bending structure which is easy to operate and can increase the ease of the pregnant women, embodies the humane care design Fetal heart rate values, bar graph and heartbeat waveform color screen display Alarming in red when the fetal heart rate range is out of the normal range Battery status indicator The probe can be changeable Probe inspection Built-in speaker Output for headphone Auto shut off Two pieces of standard 1.5V alkaline battery available which can work no less than 8 hours
Specification: -Working frequency: 2.0 MHz ± 10% -Ultrasonic output power:: Iob≤10 mW/cm2 -Overall Sensitivity: ≥ 90 dB (Integrated sensitivity 200mm away from the the surface of the probe) -While measuring integrated sensitivity, using the Doppler frequency (300 ± 50) Hz -Reflecting target speed: 10cm / s ~ 40cm / s -FHR measuring range : No narrower than 50bpm-240bpm (± 2bpm). (Beat Per Minute) -FHR Accuracy: ± 2 BPM -Spatial-peak temp-peak acoustic pressure:≤ 0.1 MPa. -Negative Peak Sound Pressure:(p_)<1Mpa -Output Beam Intensity:(Iob)<20mW/cm2
Products Show
Our Company
Shenzhen Huge Creation Technology Co.,Limited, an enterprise established in 2011, integrating R & D, producing and sales. Located in beautiful and modern city, Shenzhen, China. We are a professonal manufacturer of high quality home medical equipment and oral clean products more than 9 years of experience. In 2019 we move to bigger Industrial area, now our factory covering an area of 1500 square meters, with more then 80 workers.
To provide customers with the most cost-effective products has been our goal.
Most of our company are with our own design and technology patent. OEM survice& ODM service are our main business.
Factory address: The 2nd Floor, Bulding 6, Donglongxing Industry Park, 46# Huaning Road, Longhua district,Shenzhen city, China. Post code: 518109
