Best price lcd module 2:3 screen display 320x480 pixels 3.5 inch tft ili9488 with capacitive touch panel
LCD Size
3.5 inch
Resolution
320(RGB)x480
Aspect Radio
2:3
Contrast Ratio
500
Outline Dimension
55.04 x 84.71 x 3.65
Active Area(HxV mm)
48.96 x 73.44
Viewing Direction
12 O’clock
Interface
RGB/MCU, 51pins
LEDS (Serial/Parallel)
6 leds serials
Luminance(cd/m2)
250
Backlight Supply Current/Voltage
20mA, 19.2V
Operating Temperature
-20-+70
Company Information
Packaging & Shipping
FAQ
1.Q: Order process A:PO is placed by clients → PI is issued by Formike → Payment by clients → Lead time is confirmed by Formike → Shipping instrction by Clients → Delivery → Cargo tracking → Receipt of cargo
2.Q: Lead time ( after payment is confirmed) A: Sample: 1-10 working days Volume: 3-60 working days
3.Q: Payment A: T/T , Western union, L/C, Credit card, and Cash
4.Q: Warranty A: 12 months warranty ( Please find more details via our datasheet by item of Limited Warranty)
5.Q:RMA Process A:Claimed by cliens with photos or videos → Sales rep of Formike confirm if have questions → Sales rep issue RMA No to clients if confirmed by QA → Return to Formike → Formal report after goods received by Formike → Clients confim the analysis report → Proceeding as per the Report both agreed
6.Q:Notes A:Please check both appearance and function of products prior to installation. Any damage caused by improper use or unprofessional installation is not covered under warranty.
