UV single Roll Coater For Wood
Specification:
1. The machine coats a variety of flat surfaces, such as plate, plastic, tile and metal. It ensures a smooth and full paint coat with no chromatic defects.
2. The highly stable movement of the doctor roller and the worktable is controlled by an independent screw jack.
3. The doctor roller and rubber roller are controlled by independent transducers and reducers, which guarantee high precision.
4. Equipped with an imported scraper blade that is durable and solvent-proot.
5. This new coater can use many types of paints, such as PU, UV and NC water- based. The unuse paint can be reclaimed rapidly without any waste.
Parameter
Type | ERCS-600 | ERCS-900 | ERCS-1300 |
Working width | 600mm | 900mm | 1320mm |
Working height | 80mm | 80mm | 80mm |
Min. working length | 300mm | 300mm | 300mm |
Feeding speed | 0-20m/min | 0-20m/min | 0-20m/min |
Coating power | 0.75kw | 1.5kw | 1.5kw |
Feeding power | 0.75kw | 1.5kw | 1.5kw |
Overall Dimensions | 1000×2000×1550mm | 1000×2450×1550mm | 1000×2750×1550mm |
Net Weight | 1100kg | 1300kg | 1500kg |
