Long cycle lifes lifepo4 battery 72v for electric motorcycle use in lithium battery 12v 20Ah
LFP is implanted in traction applications, but also in energy storage applications such as self-efficiency, Off-Grid or UPS systems.
◊Major advantages of Lithium Iron Phosphate:
◊Very safe and secure technology (No Thermal Runaway)
◊Very low toxicity for environment (use of iron, graphite and phosphate)
◊Calendar life > 10 ans
◊Cycle life : from 2000 to several thousand (see chart below)
◊Operational temperature range :up to 70°C
◊Very low internal resistance. Stability or even decline over the cycles.
◊Constant power throughout the discharge range
◊Ease of recycling
◊5 years warranty
◊Pollution-free, environment friendly
◊Simplifying battery management system (BMS) and a battery charger
◊Factory price
In standard environment, and for 1C cycles, we can get from the chart the below life cycle estimation for LFP :
◊2000 cycles at 100% DoD
◊3000 cycles at 80% DoD
◊8000 cycles at 55% DoD
Model | Motorcycle LiFePO4 battery |
Nominal Voltage | 12.8V |
Nominal Capacity | 20Ah |
Cell Inside | 3.2V 3300mAh 26650 Cells |
Cell Combine | 4S6P-24PCS Cells |
Storage Energy | 240Wh |
Charge Cut Off Voltage | 14.6V |
Discharge Cut Off Voltage | 10.6V |
Battery Box Size | 76*166*181mm |
Battery Weight | 3.0KGS |
BMS Inside | 12V 4S 30A |
Rated Power | 360W |
Charger | 2A or 4A or 5A for your choice |
Total Rated Power | 2160W |
6S1P combine to | 72V 20Ah LiFePO4 battery |
Voltage | Dimension | range | BMS | CellTerminals |
12V 20Ah | 181x76x166mm | 10W-360W | 30A | 3300mAh |
12V 40ah | 182x130x195mm | 10W-360W | 30A | 3300mAh |
12V 100Ah | 340x270x170mm | 10W-1200W | 100A | 100Ah |
12V 200Ah | 335x200x335mm | 10W-1200W | 100A | 200Ah |
24V 100Ah | 310x270x270mm | 10W-2400W | 100A | 100Ah |
48V 100Ah | 473x440x221mm | 10W-5000W | 100A | 100Ah |
48V 200Ah | 340x450x650mm | 10W-5000W | 100A | 200Ah |
48V 400Ah | 998x778x379mm | 10W-5000W | 100A | 400Ah |
Cells: 3.2v 3300mah 40ah 60ah 100ah 200ah 300ah 400ah / OEM ODM Outer size: Accept to OEM/ODM PCM/BMS: Included and accept to OEM ODM customized Fit For: electric vehicle, scooter, balance vehicle, golf cart, electric equipment ,UPS,solar wind inverter syster etc. |
All batteries will be produced upon order confirmed, they will be sent out within 7 days after the payment verification. Shipping Time depends on destination and other factors.
Free Shipping and Free Customs Taxes to USA, UK, EU countries, Australia, Thailand, Dubai....
We are not responsible for any customs tax if occurs, but we will declare a reasonable low value to help buyer reduce it.
Package Include
6PCS lithium battery motorcycle 12v
1PC lithium battery charger
Strict Quality Control: Cell test and battery pack test before producing & delivering.
As usual, we produced a batch of cells, and need do below test firstly.
a) capacity test,
b) high current discharge test,
c) low temperature test,
d) cycle performance test,
e) short circuit test,
f) overcharge test,
g) crush test,
h) impact test,
i) vibration test,
j) hot test.
Strict Quality Control: Cell test and battery pack test before producing & delivering.
As usual, we produced a batch of cells, and need do below test firstly.
a) capacity test,
b) high current discharge test,
c) low temperature test,
d) cycle performance test,
e) short circuit test,
f) overcharge test,
g) crush test,
h) impact test,
i) vibration test,
j) hot test.
Q1. What is your terms of packing?
A: 1PC battery will be packed into 1PC carton
Q2. What is your terms of payment?
A:100% TT
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 7 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build customized as your requirement .
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
Q8:What's your MOQ ?
A:1PC .
Q9: Do you accept customized battery ?
A: Yes
Q10:What's your payment?
A:Bank transfer(hangseng bank ),Alibaba ,Paypal,Credit card ...
Q11: Do you accept Euro payment ?
A: Yes
