Product Description





EUCHNER Limit Switches SN03D08-552-M pn 085903







Feature:




DesignLong housing
Housing materialReinforced thermoplastic
Weight
Net0,1 kg
Ambient temperature-20 ... 80 °C
Degree of protectionIP67
Mechanical life1 x 106
DesignUpright
Housing materialDie-cast aluminum, anodized
Weight
Net0,15 kg
Ambient temperature-5 ... 80 °C
Degree of protectionIP67
Mechanical life10 x 106
Contact materialSilver alloy, electro-gold-plated
Switching principleSnap-action switching contact
Plunger spacing8 mm
Installation positionAny
Tightening torque
Screw terminal switching elementHexagon socket head screw AF 1.27mmmax.0,2 Nm
Number of switching elements3
Number of changeover contacts3
Connection
2 xM16 x 1.5
Approach speed
max.0,01 ... 20 m/min
Actuating elementChisel plunger
Actuating forcemin.15 N

Electrical connection ratings

rated thermal current Ith6 A
Utilization category according to EN 60947-5-1
AC-152A 230V
DC-132A 24V
Short circuit protection according to IEC 60269-1
(Fuse)6A gG
Rated insulation voltage Ui250 V
Rated impulse withstand voltage Uimp2,5 kV
Switching current
Min. at DC 24Vmin.10 mA
Connection cross-section0,14 ... 1,0 mm²
