LT2804 280HP 4WD FARM TRACTOR



1. Main Fillings

1). Shangchai six cylinder engine (turbocharger, intercooling)is designed with 12 hours rated power(206kw).

2). Fully enclosed cab, air heater, air conditioner.

3). Fast transmission, 18+9 shifts, shifting synchronizer.

4). Integrated frame, driving system with modularized structure.

5). CARRARO front axle,construction machinery rear axle.

6). Caliper disc brake.

7). Double rear tire.

8). Revolution for power output shaft of dual revolution 540/1000r/min.

9). Fully hydraulic front wheel steering.

10). Three groups of single/dual action hydraulic output.

11). Plough depth control method by position, floating control.

12). Suspension mechanism of rear-mounted Category III.



2. Main Specifications

Model				LT2804
	Power/speed		kW/r/min	206(280)/2200
	Specific Fuel Consumption		g/kw.h	≤230
Drive Type			/	4×4
Dimension(Length/Width/Height)			mm	6230/2500 (dual3800)/3490
Wheel Base			mm	3220
Track(Front wheel)			mm	2070-2154
Track(Rear wheel)			mm	1966-2582
Min. Ground Clearance			mm	450
Min.running weight			kg	10000
Front counter weight			kg	1000
Rated Traction Force			kN	60
No. of gear				18F+9R
Forward Gear		Speed	km/h	2-36
Reverse Gear		Speed	km/h	2-21
Tyre Model		Front Tires	/	18.4-30R1
		Rear Tires	/	20.8-38R1 (dual)
Power-output shaft Type			/	Rear position or independent
power-output shaft Rated Speed			r/min	540/1000
Max. Pull-down piston pull			kN	50
