Green Pvc Coated Wire Coat Hot-dipped Galvanized Welded Garbion Mesh



Product Description



We supply Galvanized Welded Wire Mesh, Stainless Steel Welded Wire Mesh and

PVC Welded Wire Mesh with high quanlity,favorable price and excellent service.

1) Material about welded wire mesh

Electro galvanized wire, hot-dipped galvanized.



[Electro galvanized]

Electro galvanizing, uniform coating and thin thickness. Coating are usually only 3-15 microns with bright appearance. Common electro galvanized wire on zinc amount is 8-13 g/m².
[Hot-dipped galvanized]
Hot-dipped galvanized, coated thickness and nonuniform coating. Coating are usually 45-300 microns with darker color and good corrosion resistance. Hot-dip galvanized wire amout of zinc: 30-60 g/m²



2) Welding Type

Electro galvanized before welded wire mesh

Electro galvanized after welded wire mesh

Hot-dipped galvanized before welded wire mesh

Hot-dipped galvanized after welded wire mesh

Iron/galvanized wire+pvc coated

Specification



Specification List of Welded Wire Mesh:
Opening		Wire Diameter
In inch	In metric unit(mm)
1/4" x 1/4"	6.4mm x 6.4mm	22,23,24
3/8" x 3/8"	10.6mm x 10.6mm	19,20,21,22
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21,22,23
5/8" x 5/8"	16mm x 16mm	18,19,20,21,
3/4" x 3/4"	19.1mm x 19.1mm	16,17,18,19,20,21
1" x 1/2"	25.4mm x 12.7mm	16,17,18,19,20,21
1-1/2" x 1-1/2"	38mm x 38mm	14,15,16,17,18,19
1" x 2"	25.4mm x 50.8mm	14,15,16
2" x 2"	50.8mm x 50.8mm	12,13,14,15,16
Note: Standard roll length: 30m;width: 0.5m to 1.8m





Welded Fencing Mesh Panel (In 0.5-5m Length, Width of 0.5-2.5m)
Mesh		Wire Diameter
(Inch)	(mm)	(mm)
2×3	50×75	2.0/2.5/1.65
3×3	75×75	2.67/2.41/2.11/1.83/1.65
2×4	50×100	2.11/2.5
4×4	100×100	2.0/2.5
2×8	50×200	3.0/3.5/4.0/4.5/5.0



PVC Coated Welded Mesh
Opening		Wire diameter (BWG)
In inch	Metric unit(mm)
1/2''×1/2''	12.7mm×12.7mm	16,17,18,19,20,21
3/4''×3/4''	19.1mm×19.1mm	16,17,18,19,20,21
1''×1''	25.4mm×25.4mm	15,16,17,18,19,20

Application



Used in the industry ,agriculture ,construction,transport and mining .

Such as machine protection cover ,ranch fender ,garden fender ,window protection fender ,passage fender ,fowl cage ,egg basket and foodstuffs basket.

Packaging & Shipping



Packing:

1. In rolls,plastic bags or waterproof papers
2. Square wire mesh panels,packed into plastic bags and pallets.











Loading is very important for a mesh export Factory .Even though your product have a perfect quality,but if there is a problem with packing,all of your high quality products will not be proud.
Not only should we consider the preservation of the goods, but also consider the convenient removal for the customer.That's what we've been working on for over a decade.The packing of the welded mesh products is our advantage.

Many countries'clients have cooperated with us so far because of this advantage.
