Product Description
wireless call bell wireless elevator call button bjhp calling system Video Demo Fully waterproof Anti-sabotage FM >100 floors
PRODUCT DESCRIPTION.
This Construction Site Elevator Calling System mainly used in floor construction, high-way construction, bridge construction ect.
This product mainly composed of the high brightness LED lamp,imported MIC receiver chip and PIC micro processing chip, can be stored fifty pagers at the same time.Beautiful and fashionable appearance,high-grade,generous and well-made.Applied to all kinds of business and service places,with receiving extra-long distances,long standby time and high cost-performance characteristics.
PERFORMANCE CHARACTERISTICS.
1.Built-in 500mah polymer lithium battery, still standby for more than seventy-two hours when power off.
2.Can be stored 30 or 50 pagers.
3.Support the timing display. Can be set to 5-150 seconds.
4.Support sixteen levels volume control.
5.Support three kinds of the number cancellation ways:through the host to set an automatic cancellation ;press the "enter"button of the host to cancel ;press the "cancel"button of the pager to cancel.
6.Can receive and display 30 or 50 articles calling information.
7.Learning type code, automatic saving and testing technology.
8.Support varies installation methods: hang/ flat.
9.Adopt to the imported CPU control chips and the digital coding technology, excellent performance,strong ability of the information received and processed.
HOW TO USE.
1. Install the host machine (CS-30L or CS-50L) in the elevator, and install the call button (CS-T1) in each floor;
2. Push the call button(CS-T1) when the workers need the materials;
3. Host(CS-30L or 50L) receivers call button(CS-T1) signal, the screen displays the floor number and voice broadcast;
4.The elevator operator saw the information and sent the materials to the workers.
Specification
Name | Wireless call button |
Model | CS-T1 |
Color | Grayish white |
Modulation | FM |
Shell material | ABS+Silica gel |
Size(mm) | 106*19*57 |
Launch distance(m) | >700 |
Key material | Silica gel |
Frequency | 433.92MHz |
Battery | 12V23a 1pc |
Installation way | Hanging |
Waterproof rating | IPX7 |
Logo lable | Free customization |
Weight(kg) | 0.08 |
Name | wireless receiver |
Model | CS-30L |
Weight(kg) | 0.5 |
Modulation | FM |
Frequency | 433.92MHz |
Meterial | ABS |
Color | Orange |
Battery | Built-in 600 mAh lithium battery |
Size(mm) | 184*145*30 |
Atenna | Retractable antenna |
Power | 5V1A |
Capacity | 30 |
Label | Support customization |
Power switch | built-in |
Name | wireless receiver |
Model | CS-50L |
Weight(kg) | 0.5 |
Modulation | FM |
Frequency | 433.92MHz |
Meterial | ABS |
Color | Orange |
Battery | Built-in 600 mAh lithium battery |
Size(mm) | 184*145*30 |
Atenna | Magnetic base antenna |
Power | 5V1A |
Capacity | 50 |
Label | Support customization |
Power switch | built-in |
