DOT/E-mark LED Snowplow передняя фара для грузовых

DOT/E-mark LED driving headlight for snowplow light with high beam low beam position light indicator light

Head Light With High beam, low beam, park Light, indeicator
High beam: 38 W, Low beam: 20W,Indicator: 20w, Park light: 1.5w
LEDs: Cree LED, Luminous led chip
Low Beam: raw lumens 1800Lm/effective Lumens 1500Lm
High Beam: raw lumens 5400Lm/effective Lumens 4590Lm
Indicator Light: raw lumens 400Lm/effective Lumens 320Lm
Park light: raw lumens160Lm/effective Lumens 130Lm
High beam: 784Lux@10m
Low beam: 265Lux@10m
Beam pattern: high beam / low beam 60°
Input voltage: 10-30V DC

Size: 229*150*80mm
Optic system: TIR optic lens system, side reflector facing technology (light transmittance>95%)
Electric system: Integrated ETM Technology
IP Rate:IP68 Waterproof
Life Time:50,000+ Hrs
Dual mount: bottom / back mount
Multidirectional mounting for signal light: left / top / right
Snow-melt and anti-icing system ( patented technology )
Approved by DOT, ECE ( R112 / R7 / R10 / R6 ), REF.12.5

More detail information about this snowplow light is needed, Please contact us at any time.
