Автоматический мини-привод для использования в автомобильном

Описание и отзывы

Характеристики



Product Name	Mini Actuator
Use for	Car Mirror Parts
Model NO.	MM001
Operating Voltage range:	9V-16.5V DC
Operating Voltage:	12V
Operating Current:	Inom < 100 mA
Stall Current:	Islip <125 mA
Travel Time:	5-8s
Operating Endurance :	15000times
Operating Temp. Range:	-40℃--80℃
High Temp. Range:	2500times  80℃± 5℃
Low Temp. Range:	2500times -40℃ ± 5℃
Mannual Torque:	0.25-0.85N.m
Electrical Torque:	0.25-0.50N.m
Adjustable Angle:	>20°
Noise Output:	<52dB(A)



Mini Actuator for Car	Medium Actuator for Bus	Large Actuator for Truck	Mirror Actuator
Mirror Power Foler	Side View Mirror Actuator	Mirror Motor	Hemispherical Actuator



Superior Raw Material



All the raw materials shall be stored only after the serious inspection and corresponding inspection report.



Mold



Customized mechanical seals can be manufactured according to your samples or drawings



Inspection



Strict QC system to control product quality during whole production.



Regular inspection shall be conducted on those semi-finished products in the process of producing so as to ensure the scientificness of our technique and the controllability of the inferior products.



Pre-shipment

100% quality control before shipment



Quality Management



The professional Quality Management is the guarantee of your satisfaction for the appearance and specification of our products.







More



Try order

One shipment with different items and orders

Sub dispatch by plan

Warehousing service

Insurance service

Brand build support

POP Material

Market survey and strategic adjustment support

If you need any other support, just tell us.
