ELECTRIC WIRE ROPE HOIST

STANDARD DOUBLE-RAIL ELECTRIC WIRE ROPE HOIST





Usage:

Standard Double-rail Crab, Electric Wire Rope Hoist

Widely used in factories, mines, harbours, warehouses, cargo storage areas and shops, essential in raising working efficiency and improving working conditions.

.



Product Details:

3.2 ton to 20 ton Standard Double-rail Crab Electric Wire Rope Hoist



Features and advantages:

1. Particularly favorable hook paths.

2. Anti derailment and lift-off protection design.

3. Makes optimum use of headroom.

4. Excellent approach dimensions thanks to compact design.

5. The main parts of it adopt high quality material to ensure durability.

6. Special specifications and marks can be made according to customers' requirements.

7. High quality and wide adaptation.

8. Excellent performance and safety.

9. 1 year warranty

10. Sample order, OEM and ODM orders are all acceptable.



Pharameter:

Type	Capacity(t)	Classification	Rope Reeving	Lifting Speed(m/min)		Motor Power(kw)	Hmin(mm)	H1(mm)	S(mm)	Lifting Height(m)
				Single Speed	Double Speed
SYSH5	3.2	M4	2/1	7	7/1.6	4.5	212	783	0.0182H	/	9	12	18	24	30
	6.3		4/1	3.5	3.5/0.8	4.5/1.1	232	795		6	9	12	15	/	/
SYSH6	5	M4	2/1	7.6	7.6/1.8	7.5	302	818	0.0191H	/	9	12	18	24	30
	10		4/1	3.8	3.8/0.9	7.5/2	312	830		6	9	12	15	/	/
SYSH7	8	M4	2/1	8	8/2	13	362	892	0.0194H	/	9	12	18	24	30
	16		4/1	4	4/1	13/3.4	290	1042		6	9	12	15	/	/
SYSH8	10	M4	2/1	6.4	6.4/1.6	13	362	892	0.0194H	/	9	12	18	24	30
	20		4/1	3.2	3.2/0.8	13/3.4	290	1042		6	9	12	15	/	/
