WCu rod/plate/disc/ring tungsten copper alloy factory
Product Description
Specifications: Hot sale tungsten copper bars China
1.Product name: Tungsten Copper Alloy Bar/Sheet
2.Material: Tungsten Copper (WCu)
WCu rod/plate/disc/ring tungsten copper alloy factory
1.Specifications:
Diameter: as required
Density: W90Cu10 17.2g/cm3, W80Cu20 15.5g/cm3, W85Cu15 16.4g/cm3, W70Cu30 14.5g/cm3
2. Types, chemical compositions and properties of W-Cu alloy rod:
Type | Chemical composition of copper tungsten alloy (%) | resistivity(cm) | tensile strength(kg/mm2) | hardness | density(g/cm3) | |
W | Cu | |||||
F6002E | 60 | balance | <=3.26*10-6 | >=130 | >=160 | >=12.70 |
70 | <=3.80*10-6 |
| >=200 | >=13.80 | ||
80 | <=4.00*10-6 |
| >=220 | >=15.00 | ||
3. Applications of W-Cu alloy rod:
Sealed cap for transistors sealing welder, contactor materials for high voltage switches and electrodes for spark processing etc.
4. Character:
1. Better heat resistant;
2. better ablate-resistant;
3. High intensity
4. High density;
5. Excellent thermal and electrical conductivity;
6. easy to be machined.
