Energy Battery Storage Inverter power inverter with battery box

Описание и отзывы

Характеристики

	GSP-5.0T	GSP-6.0T	GSP-8.0T	GSP-10.0T
Max.recommended DC power[W]	6000	8000	10000	13000
Max.DC voltage[V]	1000	1000	1000	1000
Norminal DC operating voltage[V]	720	720	720	720
Max. short circuit current[A]	14/14	14/14	14/14	23/14
MPPT voltage range[V]	230-800	280-800	370-800	330-800
No. of MPP trackers	2	2	2	2
Norminal AC power [VA]	5000	6000	8000	10000
Max. AC power [VA]	5000	6000	8000	10000
Rated grid voltage(AC voltage range) [V]	400(360 to 440)	400(360 to 440)	400(360 to 440)	400(360 to 440)
Rated grid frequency [Hz]	50/60	50/60	50/60	50/60
Norminal AC current [A]	7.6	9	12.2	15
Max. AC current [A]	8.5	10	13.5	16
Battery voltage range [V]	170-500
Recommended battery voltage [V]	200	240	320	400
Max.charging/discharging power [W]	6000	8000	10000	10000
Max.charging/discharging current [A]	25
Communication interfaces	CAN/RS485
Reverse connect protection	No
EPS rated power [VA]	5000	6000	8000	10000
EPS rated voltage [V], Frequency [Hz]	400/380, 50/60	400/380, 50/60	400/380, 50/60	400/380, 50/60
EPS rated current [A]	7.6	9	12.2	15
EPS peak power[W];Duration [s]	10000,60	12000,60	16000,60	16000,60
Switch time[s]	<0.5
Total harmonic distortion(THD, linear load) [%]	<2
Parallel operation	Yes
MPPT efficiency[%]	99.9
Euro efficiency[%]	97
Max.efficiency[%]	97.6
Battery charge/discharge efficiency[%]	96
Standby consumption [W]	<7
Idle mode	YES
EMC	EN61000-6-1/EN61000-6-2/EN61000-6-3
Operating temperature range [OC]	-25~+60 (derating at+45)
Storage temperature[OC]	-20~+60
Over voltage category	III (electric supply side), II (PV side)
Weight[kg]	40







Q1: Can I have sample order for hybrid inverter?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2: What about the lead time?

A:Sample needs 10 days, mass production needs 2-3weeks for order quantity more than one container



Q3: what’s the warranty ?

A:3 years



Q4: How can i pay the hybrid inverter ?

We could accept payment by T/T, Paypal, West union, Alibaba Trade Assurance order etc.



Q5: How can I contact  you?

Please contact us by Trade manager, Email, Whatsapp or wechat, surely call me when you need
