0 75 T мини портативный ручной рычаг с храповым
- Категории: Съемник для цепи и таль с храповым механизмом >>>
- Поставщик: Foshan,Lomba,Lifting,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Cheap Material Handling Equipment 0.5ton to 6ton Ratchet Lever Chain Hoists Lever Block
Model: HSH-B
Technical Features
1. Superior Grade 100 load chain-WAFIOS link, Din standard.
2. Forged and heat treated load hooks with batch trace ability and stretch indicators
3. 360° handle rotation with stroke to ratchet indicators
4. Double pawl brake system
5. Asbestos free brake linings
6. Forged safety latch
7. Sealed roller bearings
8. 100% load tested to 1.5xWLL
9. MBL of 400% of WLL
10. 2000 cycle batch test
|
Product code |
Capacity (t) |
Standard lift (m) |
Test load (t) |
Pulling Efforts (kg) |
Chain fall No. |
Load chain Dia. (mm) |
Dimensions(mm) |
Net Weight (kg) |
||||
|
A |
B |
C |
D |
E |
||||||||
|
HSH-B0.5 |
0.50 |
1.5 |
0.75 |
10 |
1 |
5 |
148 |
280 |
45 |
96 |
325 |
5.9 |
|
HSH-B0.75 |
0.75 |
1.5 |
1.13 |
14 |
1 |
6 |
148 |
280 |
45 |
96 |
325 |
6.6 |
|
HSH-B1.0 |
1.00 |
1.5 |
1.50 |
16 |
1 |
6 |
148 |
280 |
48 |
96 |
325 |
6.6 |
|
HSH-B1.5 |
1.50 |
1.5 |
2.25 |
22 |
1 |
8 |
172 |
410 |
52 |
110 |
380 |
10.8 |
|
HSH-B2.0 |
2.00 |
1.5 |
3.00 |
26 |
1 |
8 |
172 |
410 |
60 |
110 |
380 |
11.1 |
|
HSH-B3.0 |
3.00 |
1.5 |
4.50 |
32 |
1 |
10 |
195 |
410 |
66 |
145 |
480 |
18.2 |
|
HSH-B6.0 |
6.00 |
1.5 |
9.00 |
34 |
2 |
10 |
195 |
410 |
80 |
145 |
480 |
28.1 |
Individually proof load tested with individual serial number
Tested according to EN13157-2004
Packaging & Shipping
Company Information
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
Certificate
