Высокая-конец светодиодная рекламная грузовик

Model

YES-V6S(IZUSU chassis)

Chassis

Brand

ISUZU

External dimension

5990mm×2040mm×3100mm

Emission standard

Euro IV

Gross weight

4450KG

Engine type

Diesel

Wheel base

3360mm

Braking system

Hydraulic dual circuit

Max speed

90km/h

Silent Generator Set

External dimension

510mm×900mm×1060mm

Power

7.5KW

Power type

Yeeso

Number of cylinders

Water-cooled inline 3-cylinder

Air displacement

1.995L

Bore x Stroke

84mm x 90mm

LED Display System

LED Screen size (P10)

3200mm×1600mm(left side)

Module Size

192mm(W) ×192mm(H)

Chip

R,G,B, EPISTAR

Pixel pitch

6 mm

Brightness

≥7000cd/m²

Max power consumption

1000 W/m²

Average power consumption

500W/m²

Life span

100,000 hours

Single red color LED display size

3200mmx320mm(right side, over light box)

Scrolling Light Box

Display size

3250mm×1550mm(right side)

Roller diameter

80 mm

Motor power

≥80W

Control mode

Intelligent remote control

Mechanical Control System

LED screen lifting system

Hydraulic lifting, Lifting height: 1200mm, afford 3T(left side LED screen)

Power Supply

Input voltage

Three-phase five-wire 380V

Output voltage

220V

Electrical current

50A

Power consumption

Average: 0.5wh/m²

Multi-Media Control System

Industrial PC

Processor: dual core CPU; display card: 1G; hard disk: 500G; CD-ROM: DVD; storage card: 2G

Monitor

15-inch Industrial Display

Power amplifier

unilateral output power:

200W

Speakers

Max power consumption:200W

Control system of LED screen

LINSN

Outer Frame and Inner Decoration

Cold rolled metal plate of Outer box

1.5mm

Surface car baking varnish

Pure White

Inner decoration

Fire Retardant Board

Waterproof processing

Vehicle plastic irrigation processing
