10 метров гидравлическая подъемная платформа грузовик Воздушная Рабочая транспортных

Aerial work platform truck

#

Descriptions

Specifications and types

General

Truck Brand

Chengliwei (our brand)

Chassis Brand

Dongfeng

Approx. Dimension

5900*2000*2750 mm

GVW./Kerb Wt.

4495 / 4170 (Kg)

Cab

Cab Capacity

2+3 persons' seat

Air Conditioner

Air Conditioner is optional

Chassis

Drive Type

4x2,lefthand drive/

Righthand drive is optional

Fuel Type

Diesel

Engine Make & Model

Chongqing Wushiling

Power

         102 HP

Displacement

3707  ml

Emission Standard

Euro II or EURO III or Euro V

Wheelbase/No.of axle

3308 mm / 2

Tyre Specfication

7.00R16 8PR

Tyre Number

6 tyres and 1 spare tyre

Max Speed

100 km/h

Paint

Automative metallic paint

Tops Parts

Equipment:

a) Equipped double operation systems;

b) The operationg platform is three-section folding arm;

c) Locking fuction;

d) Four hydraulic H-shap legs which can be adjusted separately.

f) Two tool boxes.
