Двухмоторный бесщеточный esc FSESC6.6 с водонепроницаемым алюминиевым корпусом на VESC для электрического скейтборда

Upgraded features:

1,Integrated anti spark switch smart function,

2,Skate to power on automatically
3,Keep eboard still for 10minutes, it will power off,

4,Added Can bus connector, be more convenient for 4WD set up
5,Changed the USB port soldering process to SMT soldering instead of manual soldering

Spec

- Hardware: V 6.6

- Firmware: latest update
- Voltage: 8V - 50.4V (Safe for 3S to 12S LiPo) for the dual ESC

- Voltage spikes may not exceed 60V
- Current: Continuous 100A single, total 200A,  Instantaneous current 400A per single, total 800A for system instantaneous current.
- 5V 1.5A output for external electronics for single
- 3.3V 1A output for external electronics for single
- Modes: DC, BLDC, FOC (sinusoidal)
- Supported sensors: ABI, HALL, AS5047

Reminder: Detected battery voltage tolerance: +/-0.6V

The shipping package contains:

• 1*Dual FSESC6.6+Heatsink


• 2*VESC Sensor Wires


• 1*LED button


• 1*Micro USB


• 1*Manual

Other detail spec is the same with Dual FSESC6.6, you can get more information by here:

https://flipsky.net/collections/electronic-products/products/fs-esc-6-6

Shipping time: WIthin three days on weekdays

Shipping method: mail(within 15days)/DHL(within 7days)

Why choose Flipsky VESC?

1.Flipsky ESC owns many functions that a normal RC ESC does not owns.
A.To set the range of current that comes from battery to motor. Normally a motor is easily burned up by sending it more current than it can handle for too long(often while riding up a hill). This will not happen to FSESC if you have set up a safe current range for it.
B.There's also many other protections that can be set through limits, such as the the temperature(so you can avoid to burn up your speed controller), min and max voltage(so you can set your battery voltage in the safe range according to your battery spec), and max regenerative break current (protect battery from being over-charged)
2.FOC(Field Oriented Control) makes the motor more smooth and less noise and even save much power.
3.It's widely used by DIY market. DIY market people has higher requirement on product quality.They know much more details of product.
