Одноступенчатая газовая/масляная промышленная горелка

Single stage fire gas / alcohol oil dual fuel burner

1.Alternate methane gas/light oil burner

2.Single stage operation(on/off).

3.Air-gas mixing at blast-pipe and high pressure machanical atomization of fuel using nozzle.

4.Ability to obtain optimal combustion valves by regulation combustion air  and blast-pipe.

5.Maintenance facilitated by the fact that the mixing unit can be removed without having to remove the burner from the boiler.

6.Manual flow adjustment.

7.One flange and one insulatin seal for boiler fastening.

8.Combustion air intake with air flow adjustment device.

9.Sliding boiler coupling flange to adapt to head protrusion of the various types of boilers.

10.Adjustable blast-pipe with stainless steel nozzle and deflector disk in steel.

11.A Monophase electric motor to run fan and another torun the pump.

12.Flame presence check by photoresistance and ionization electriode.

13.Electrical plant protection rating IP40.

The blast tube can be Lengthened and 60Hz can be customized.

Standard accessories:

Oil filter--nozzle--the parts with the boiler
