Probest water Analyzer Manufactuer
PLTU-700 Low Range Turbidity Online Meter Analyzer Sensor And Transmitter Controller
You may find our photoes, our videoes are not good, as I do would like to show all our partners the real situation of our company and the real situation of our products.
I do know that you could find many China suppliers and many quotation. But it is a headache to find a reliable long terms partner. Please give both of us a chance, as we are a relialbe direct factory in Fuzhou, China:
Probest- Our main advantages:
1.30+ R & D personnel to keep us moving together
2.Many patents & software copyrights to ensure products meet markets
3.ISO9001 authorized factory
4.100% inspection & test ensure quality
Product Description
| Model No. | PLTU-700 Low Range Turbidity Sensor and transmitter controller |
| Measurement range | 0.001-100 NTU |
| Measurement Accuracy | ±2% of the reading or ±0.015NTU (range: 0.001-40NTU),whichever is greater; ±5% (range: 40-100NTU) |
| Water flow | 300ml/min≤X≤700ml/min |
| Calibration | Standard solution calibration,water ample calibration,zero calibration |
| Pipe Fitting | Inlet:1/4NPT; Outlet:1/2NPT |
| Main material | Body:ABS + SUS316L; Seal: Butyl Cyanide Rubber; Cable:PVC |
| Power supply | AC:100-240VAC (50/60HZ) DC:9~36VDC |
| Output | 3-way 4-20mA |
| Relay | Setting three-way relays,programmed response parameter and response value. |
| Communication protocol | MODBUS RS485 |
| Storage temperature | -15-65℃ |
| Measuring temperature | 0-45℃ |
| Dimension | Sensor:310 *210*410mm(L*W*H) Transmitter:145*125*162mm(L*W*H) |
| Weight | Sensor:2.1KG;Transmitter:1.35KG |
| Protective rate | Sensor:IP68/NEMA6P;Transmitter:IP65/ NEMA4X |
| Cable length | Standard: 3m, could be extended (LED:30M, Tungsten lamp: 7M) |
| Suggested Backup spare parts | PDP-LTU Tungsten lamp |
Measurement Principle:
Incident light of PLTU-700 Low-Range Sensor is produced by the tungsten light whose color temperature’s absolute temperature is between 2200 degrees to 3000 degrees.Guiding the parallel light assembled by the tungsten light down into the water sample of the sensor,the light is scattered by suspended particles in water samples,and the scattered light that is with a ninety degree angle to the angle of incidence is received by the silicon photocell receiver in the water sample,measuring the turbidity by calculating the relationship with 90-degree scattered light and the incident beam.
Features:
1. A scattering turbidity meter with continuous readings, designed for low-range turbidity monitoring.
2. Stable data and good repeatability.
3. Easy clean and maintenance.
4. Plug-and-play sensors,quick and easy installation.
Applications:
1. Turbidity online monitoring of water inlet, settling basin of water plant.
2. Turbidity online monitoring of sewage plant,industrial process water and waste water treatment.
PRODUCT SHOW
ABOUT US
EXHIBITION
PRODUCTION PROCESS
CERTIFICATE
PACKAGE & SHIPMENT
FAQ
WHY CHOOSE US:
Probest is a professional ISO9001 certificated manufacturer with many patents specializing in researching, developing, producing of water analysis instruments, including portable water analyzer, multi-parameter water quality analyzer, data acquisition and transmission terminal. The product can be applied to the fields of water quality monitoring of drinking water, waste water, surface water, aquaculture water, industrial process water, etc.
Probest is a reliable company including 30+ researcher, focusing on the development of sensor technology to make water analysis faster, simpler, greener and better.
Quality is our core advantages, providing stable and reliable water quality analysis.
