HHD 3G планшетный ПК с функцией/антенна спутникового слежения автомобиля Грузовики замок для холодильных установок логистики

Описание и отзывы

Характеристики



 Features:

1. Free install: Just hung on the truck door, then Global Satellite will real time track the location, and will tell you where cargoes are, and what the lock state is. The accuracy locating scope is within 10 meters.

2. Preset unseal station: Users can preset customers store or station as the unseal location, only when location and the RFID card are matched, then GPS padlocks can be unsealed by the named RFID card.

If trucks are in the wrong location, the RFID card can not be used to unseal the GPS padlock.

3. Geo-fence: To limit vehicle transporting trajectory, users can preset Geo-fence to the truck, when trucks get in or get out of the Geo-fence (as operator preset), GPS padlock will send alarms to the IoT platform. Operator can manage the trucks fleet conveniently.

4. Anti-theft alerts: With insert hall sensor, light sensor, triaxial sensor, electronic sensor, GPS padlock can recognize the trucks engine vibration and in occasion of getting cut/ demolished/ tampered/ low battery, will send alerts to the on-line tracking platform, with info of Time/ Location/ Speed/ Direction/ Driver ID/ Operator ID/ Trucks ID, etc.

Users can get SMS alerts in-time, to minimize the assets lost.

5. High duty: With high duty aluminum alloy lock body and 304 stainless steel shackle rod, when locks are sealed, it can resistance more than 1,000N striking.

6. High waterproof: With IP67 waterproof, GPS Padlocks can be widely used in all indoor and outdoor logistics environments.

7. Reports analysis: All locks reports can be checked in the platform, and users can download the datas for further analysis.

 Parameter

Model	G-420	Lock/Unlock	RFID keycard, Bluetooth, Phone APP, SMS, Web-platform
Size	140mm*106mm*45mm	GPRS	GSM 850/900/1800/1900 MHz
Body Material	aluminum alloy	Charging Port	DC 5V/3A
Shackle Rod	304 stainless steel	Precise Accuracy	<10M
High Security	Mechanical & Electronic double locking	Salt Fog	IEC60068-2-11
Rod Seal	>100kg	Random Vibration	IEC60068-2-53
Battery (Li)	12000mAh, rechargeable	Mechanical Vibration	IEC60068-2-2
Battery Endurance	10 days (real-time locating) 180 days (2hrs once locating)	Humidity	95% non condensing
Display	0.96 inch screen battery, signal, lock state, time	Electrostatic Discharge	25 thousand volt
Waterproof	IP67	Warranty	1 Year
Storage	2M Flash, >8000 blind spot records stored	Certified	CE RoHS





 High-reviewed Products



GPS Padlocks	G-300N	G-300P	G-320	G-420	G-400
Images
Communication	2G	√	2G(3G Option)	2G(3G Option)	√
Unlock Method	RFID/ Bluetooth/  Phone platform/  PC platform/ SMS	+Keypad	√	√	-Bluetooth
Abnormal Alarms	Law battery  Anti-break  Anti-cut  Anti-tampered  Ilegal demolition	√	√	√	√
Environment	CE RoHS  Waterproof: IP67  Working    : -20℃ to 70℃  Salt fog     : IEC60068-2-11  Vibration   : IEC60068-2-2 & IEC60068-2-53
Shackle Material	304 stainless steel	√	flexible cable	√	√
Shackle Diameter	8mm	√	7mm	9mm	9mm
Battery	6000mAh	√	√	12000mAh	√
Battery Holding	7-90 days	√	√	10-180 days	√



 Click right side to chat now→→→→→→→→→→→→→



 Detailed Imagines



 About Our Comany





Shenzhen HHD Technology Co.,Ltd. has been working on Security Protection over 8 years with the core technology and business application platform, product diversification, complete logistics and transportation monitoring solutions.







 OEM Services
