                                                          LNG Tanker Semi Trailer

Curb weight

19477 (Kg)

Total Weight

40000 (Kg)

capacity

52600 L

Design temperature

-196(°C)

Applicable shipping medium

Liquefied natural gas(LNG)

Inside tank material

06Cr19Ni10

Adiabatic way

Vacuum \\ muti-layer adiabatic

Payload (Kg)

20553

Dimensions

13000x2500x3950 mm

Unit volume filling weight

0.39(KG/L)

Design pressure

0.68mpa

Working pressure

0.7mpa

Tank shell material

16MnR/Q345R

Adiabatic materials

Aluminum foil, adiabatic paper

(Relief valve)opening pressure(Mpa)

0.61

Axles

3 set(Fuwa 13T)

King pin

1 set 50#

Steel mechanical suspension system

1 set*3axles

24V circuit system

1 set, European Style

Loading and unloading valve

1 set

Content gauge (level gauge)

1 set

Thermal meter

1 set

Manometer

1 set

Cabinet

1 unit

Tire (12.00TriangleVacuum)

12* 12R22.5

Spare tire carrier

1 set

Pneumatic brake system

1 set

ABS

1 set

Hand tool

1 set

loading and unloading hose

1 set

Relief valve

2 set

Fire extinguisher

2 unit

Anti-static drag ground

1 unit

toolbox

1 unit with spare tools

Remarks

The vehicle is used to transport liquefied natural gas (LNG) specially. It has been applied in liquefied petroleum gas transportation already for 20 years. It has reasonable design, proven technology, safe and reliable. The design, manufacturing and inspection of our products are in accordance with the national standards:GB150, GB1589, it is equal to international standards. We can design different size tanks for users to correspond with local vehicles loaded weight standard.
