BH-90E portable gas leak detector is a new type of detector for detecting gas leakage from the gas pipelines, gas valve, and other possible places. With imported high quality semi-conductor sensor and embedded microcontroller, it has very high sensitivity, excellent man-machine operation interface and various adaptive ability.
The housing of the detector is made of high strength engineering plastics and compound anti-slip rubber. It is waterproof, dustproof, and with good handle.
1) Advanced MCU control with low power consumption
2) Adjustable low and high alarm level
3) Adjustable calibrating level
4) High concentration protection for combustible gas
5) Self test for the combustible gas sensor
6) Low battery indication
7) Replaceable sensor module
8) Self-adjustment function
9) Visual and audible alarm with vibration
10) STEL and TWA alarming for toxic gases
11) Advanced self-examination and self-renovation function
12) Password management to avoid wrong operation
13) Explosive proof housing
Detection range | (0-10000) ppm (for CH4) | ||||
Target gas | Combustible gas | ||||
Response time | T<5s | ||||
Indication way | LCD and digital indication Audible indication | ||||
Working condition Tem | -20°C~60°C | ||||
Hum | <95%RH No con | ||||
Working voltage | DC3.6V / 2100mAh Lion battery | ||||
Charging time | 4h~6h | ||||
Working time | 12h-70h | ||||
Life of gas sensor | 2 years | ||||
Protection grade | IP65 | ||||
Weight apprx | 300g (battery included) | ||||
Dimensions | 210mm×66mm×30mm |
The detector is suitable for explosion-proof, toxic gas leakage and rescue, underground pipelines, mines, metallurgy, power plants, chemicals, tunnels, etc., effectively avoiding the occurrence of poisoning accidents, ensuring the safety of workers and avoiding losses of production equipment.
No. | Detected Gas | Detecting Scope | Resolution | Low/High Alarm Point | Response Time | Detection Accuracy |
1 | PH3 | 0-20ppm | 0.1ppm | 5ppm/10ppm | ≤25s | ±5%(F.S) |
2 | O2 | 0-30%vol | 0.1%vol | 19.5%vol/23.0%vol | ≤15s | ±5%(F.S) |
3 | EX | 0-100%LEL | 1%LEL | 25%LEL/50%LEL | ≤5s | ±5%(F.S) |
4 | CO | 0-1000ppm | 1ppm | 50ppm/100ppm | ≤25s | ±5%(F.S) |
5 | H2S | 0-100ppm | 1ppm | 10ppm/20ppm | ≤30s | ±5%(F.S) |
6 | NO2 | 0-20ppm | 0.1ppm | 3ppm/10ppm | ≤25s | ±5%(F.S) |
7 | NO | 0-250ppm | 1ppm | 25ppm/50ppm | ≤60s | ±5%(F.S) |
8 | SO2 | 0-20ppm | 0.1ppm | 5ppm/10ppm | ≤30s | ±5%(F.S) |
9 | CL2 | 0-20ppm | 0.1ppm | 1ppm/10ppm | ≤30s | ±5%(F.S) |
10 | NH3 | 0-100ppm | 1ppm | 25ppm/50ppm | ≤50s | ±5%(F.S) |
11 | H2 | 0-1000ppm | 1ppm | 50ppm/100ppm | ≤60s | ±5%(F.S) |
12 | HCN | 0-10ppm | 0.1ppm | 1ppm/5ppm | ≤200s | ±5%(F.S) |
13 | HCL | 0-10ppm | 0.1ppm | 1ppm/5ppm | ≤60s | ±5%(F.S) |
14 | CH4 | 0-100%LEL | 1%LEL | 25%LEL/50%LEL | ≤5s | ±5%(F.S) |
Note: The above table is a general parameter. If you need other gas and range, please contact our online customer service.
Bosean has been committed to the development of the gas detection industry with strong economic strength and strong technical strength , specializing in the research, development, manufacturing and sales of gas detectors.We have continuously developed new products with international advanced technology.
The body of the detector is small and easy to carry. The interface is simple and easy to operate. The shell is made of high strength ABS material, IP65 protection grade, dustproof, waterproof, explosion-proof, and can withstand the test of harsh environment.
Two-level triple alarm, not easy to ignore, high and low alarm value can be set.
Metal aluminum box, machine, manual, certificate, lanyard, data cable, charger, calibration cover.
Click the picture to enter the area
Click the picture to enter the area
Q1:Are you a trading company or manufacturer ? | ||||||
A1:We aremanufacturer. |
Q2:What about the payment method? | ||||||
A2:T/T, Paypal, Western Union, L/C is available. |
Q3:Does your company accept customization? | ||||||
A3:We do customizing service for customers. |
Q4:What about the Shipment? | ||||||
A4:We'll choose proper transportation mode based on the weight of goods, usually arrange shipment by air express such as DHL,FEDEX,TNT or UPS. | ||||||
Q5:What about after-sale service? | ||||||
A5:12 months warranty for all kinds of products. | ||||||
Bosean was founded in 2013, specializing in the development and production of gas detectors, gas analyzers and rangefinder. At present, our research and development instruments have been spread all over the world.
Bosean has always strictly implemented the ISO9001 quality management system. We adhere to the high standards of product quality, strict requirements, adopting the world-class production equipment, advanced management and production experience, developing the high-quality testing equipment.
Bosean has a strong sales team and a comprehensive service process to serve end customers around the world.Whenever you have any questions, you can contact us at any time.
Bosean has an independent warehousing base. It integrates instrument research and development, manufacturing, warehousing and delivery. It supports small batch spot delivery and mass customization.
Providing a variety of express and different modes of transportation to ensure the safe and timely arrival of goods. Supporting multiple payment methods.
