Products Description
High Quality 40Ft Side Wall Semi Trailer Mechanical Brake System Fiberglass Cargo Box Trailer
600mm Fence and 1200mm sidewall truck trailers
Dropside Sidewall Trailer Technique Dates,
Dimension (L*W*H) | 13000*2500 (fence height 1600 / 1800) |
Tare Weight | 7.5t |
Axle | 13T, 1-4 pcs, BPW or FUWA or Yonglitai or Huajin Brand |
Leaf Spring | 90*13-10, 6/8 sets, FUWA alxe Funiu alxe Taiyue axle etc. |
Suspension system | Mechanical Suspension / air suspension / single point suspension (Germany Type or America Type or Japan Type) |
Main Beam | Material: Q 345 Carbon Steel. Beam height: 500 mm. Upper plate: 14 mm, Bottom Plate: 16 mm, Middle: 6/8 mm |
Side Beam | 14#/16# channel steel (Q235) |
Cross member | 8#/10# channel steel (Q235) |
Platform | 3mm checker Plate or flatbed |
Side wall height | 600mm/800mm/1000mm etc |
Tire | 12R22.5-18, 12units |
Landing Gear | Standard 28Ton, JOST or FUWA etc. |
Brake system | WABCO available. 4 sets T30/30+2 sets T30 chamber; Two 40L tanks, ABS Optional |
Electrical system | 1. Voltage:24V， LED lights 2. Tail light, brake light & reflector, side lamp etc. 3.Receotacle:7 ways (7 wire harness) |
High Quality 40Ft Side Wall Semi Trailer Mechanical Brake System Fiberglass Cargo Box Trailer
High Quality 40Ft Side Wall Semi Trailer Mechanical Brake System Fiberglass Cargo Box Trailer
1800mm sidewall fence trailer Function
1.It can carry all kinds of cargo, mainly for farm and logistics, such as agricultural products, light cargo, animals, vegetables, fruits etc.
2.It can be customized, give you the one most suitable.
3.The structure is simple and easy dismantling, reasonably designed for different goods, to meet the fully weight situation and reduce cost.
2.It can be customized, give you the one most suitable.
3.The structure is simple and easy dismantling, reasonably designed for different goods, to meet the fully weight situation and reduce cost.
Dropside sidewall Trailer Technique Dates,
3 Axle with 1800mm dropside sidwall
Strong Sidewalls
Checkered Plate
Production in workshop
Tool Box
air chamber
Company Profile
Shandong Yuncheng Xinya Trailer Manufacturing Co., Ltd. was established in June 2010. It is the "bulletin" enterprise of the Ministry of industry
Main Semi Trailers: container Chassis trailer, van trailer, flatbed trailer, fence semi trailer, self-unloading trailer, dump trailer, wing open trailer, tank trailer, car trailer, glass fiber plate trailer, and spare parts.
Workshop I: Chassis production line 1
Chassis trailer, flatbed semi trailer, low bed trailer
Workshop 2: Chassis production line 2
Van box semi trailer, Curtain Semi Trailer
Workshop 3: Chassis production line
Fence semi trailer, sidewall semi trailer
Workshop 4: Chassis production Line 4
skeletal container chassis trailer
Workshop 5 : Powder tanker semi trailer production
cement tanker trailer V shape and W shape Trailer
Workshop 6: fuel tanker semi trailer production line
Fuel tanker trailers
Workshop 7: Van box trailer production line
Van box trailer , curtain semi trailer
Workshop 8: Curtain Trailer, Van trailer production line
Warehouse Show
Warehouse Corner 1: Center Pin
Warehouse Corner 2: U Shape Rod
Warehouse Corner 3: Suspensions
Warehouse Corner 4: Alexs
Warehouse Corner 5: Painted Suspension
Warehouse Corner 6: Suspensions
Ready for ship to Clients
Customer Photos
We exported the flatbed trailers, sidewall trailers, Fence trailer, dump trucks, tipper trailers,Low bed trailer to all over the world, especially for the Africa Market and Mid east markets, the clients come from Djibouti, Ghana, Mozambique, Mauritania, Saudi Arabia, Tanzania, Benin, Indonesia, Thailand and so on.
