Huasen дырокол для изготовления обуви гидравлический четырехколонный режущий станок хорошего
- Категории: Станки для обуви >>>
- Поставщик: Yancheng,City,Huasen,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Description & Detail
SPECIFICATIONS FOR PVC SLIPPERS MAKING MACHINE/PU SHOE MAKING MACHINES | ||
Model | HSC500 | |
Maximum Cutting Force(KN) | 500 | |
Tension Distance(MM) | 50-200 | |
Cutting Area(MM) | 1600*800 | |
Motor Power(KW) | 4 | |
Gross Weight(KG) | 3800 | |
Technical Specification
1.The machine is widely applicable to cutting of various nonmetal materials by die cutter.
2. Double oil cylinder and precise double-crank connecting rod balancing mechanism are adopted,which can guarantee that the cutting depth at every cutting position is same.
3. With special setting mechanism,and in conjunction with die cutter and cutting depth setting, the travel adjustment is simple and accurate.
4. The pressing board of cutting carries out slow cutting when it contacts the die cutter, which can make that there is no size error between the uppermost layer and lowermost layer of cut materials.
5. The central oil supply automatic lubricating system guarantees machine precision and prolongs service life of machine.
6. Products of special specifications can be customized. The maximum cutting force can reach 4000KN.
2. Double oil cylinder and precise double-crank connecting rod balancing mechanism are adopted,which can guarantee that the cutting depth at every cutting position is same.
3. With special setting mechanism,and in conjunction with die cutter and cutting depth setting, the travel adjustment is simple and accurate.
4. The pressing board of cutting carries out slow cutting when it contacts the die cutter, which can make that there is no size error between the uppermost layer and lowermost layer of cut materials.
5. The central oil supply automatic lubricating system guarantees machine precision and prolongs service life of machine.
6. Products of special specifications can be customized. The maximum cutting force can reach 4000KN.
Certifications
Our Advantage
Brand Touch Screen
This machine adopt centralized PLC and man-machine interface operation, set stroke adjusting convenient with high precision.
Hydraulic System
The special hydraulic system can make sure the cutting force. We can make sure the reality cutting force for our clients.
Precise Four-column
This machine is guided by precision four-column, balanced by precision double crank and drived by hydraulic. All moving parts adopt automatic lubrication system to ensure the service life and precision.
Electric System
This machine adopt clear wire which can easy to troubleshoot. Comply with EMC electrical standards (grounding, wiring, shielding, etc.)
Packing & Delivery
Packaging | ||
Size | To Be Advised | |
Weight | 4T | |
Packaging Details | The normal package is wooden box and wooden pallent. If export to european countries,the wooden box will be fumigated.We also use eco-friendly composite wooden board. If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
Packaging | ||
Size | To Be Advised | |
Weight | 4T | |
Packaging Details | The normal package is wooden box and wooden pallent. If export to european countries,the wooden box will be fumigated.We also use eco-friendly composite wooden board. If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Professional solutions.
* Quickly response.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
* Quickly response.
* One year warranty.
Related Products
Die cutter machine for leather
Cutter machine leather cutting presses
Movable head travel head cutting machine
Single-sided double slide hydraulic plane cutting machine/Shoe machine
HS-2500A Highly-efficient and Energy-saving Mesh Belt Laminating Machine
Automatic Hydraulic Conveyor Belt Four-Column Cut Presses Machine
About Us & Partners
Yancheng City Huasen Macinery Co.,Ltd is established in 1980s and located in Gangzhong Industrial Park, Yandu District, Yancheng City,Jiangsu Province.
We are a experienced and professional hydraulic pressure die cutting machinery and laminating machinery manufacturer in China. We manufacture and export various cutting machine, die cutting machinery and auxiliary equipment of nonmetal materials for domestic and international customers such as: Shanghai Volkswagen, Janpan Toyota, USA 3M,Germany BOS,BYD Auto and Wuhan Shenlong ect.
We has beed granted more than 10 national patents and own independentintellectual properties. Currently our main market is Domestic, Europe, USA, Japan, South Korea, South America and Africa etc.
