Product Description
• Pressure clamp connectors
• Dynamic heating up
• Wide voltage range
• Energy saving
• Clip fixing, Quick installation
These heaters are used in enclosures where damage from condensation must be prevented, or where the temperature
may not fall below a minimum value. The aluminium profile heater body design has a chimney effect and distributes
the heat evenly
. The heaters are designed for permanent operation. Pressure clamb connectors save time and simplify
installation.
NTL 150 | ||
Operating voltage | 120-260V AC/DC or 12V DC or 24V DC or 48V DC¹(min. 110V, max. 265V) | |
Heating element | PTC resistor - temperature limiting | |
Heater body | extruded aluminium profile, anodised | |
Connection | 3 pressure clamps for stranded wire 0.5-1.5mm² (with wire end ferrule) and rigid wire 0.5- 2.5mm² | |
Connection casing | plastic according to UL94 V-0, black | |
Mounting | clip for 35mm DIN rail, EN 60715 | |
Fitting position | vertical airflow (air outlet up, connection on bottom) | |
Operating/Storage temperature | -45 to +70°C (-49 to +158°F) | |
Operating/Storage humidity | max. 90% RH (non-condensing) | |
Protection type/Protection class | IP20 / I (earthed) | |
Accessoires
| screw fixing, Art. No. 09024.0-00 (1 packing unit = 2 pieces) | |
Note | other voltages on request | |
¹Operating with voltages below 140V AC/DC reduces heating performance by approx. 10%.
