3 5 "qvga tft 320x240 LQ035NC111 54 булавки с ЖК-дисплеем для Портативный прочный можно крепить любые приспособления: pda портативный навигатор ЖК-экраном цифровой
- Категории: LCD Module >>>
- Поставщик: Shenzhen,Huai,Zhi,Technology,Co.,Limited
Поделиться:
Описание и отзывы
Характеристики
Product Description
3.5"qvga tft 320x240 LQ035NC111 54 pin LCD for handheld rugged pda portable navigation digital camera lcd screen
General Features | |||
Screen Size | 3.5 inch | Type | a-Si TFT-LCD , LCM |
Pixel Number | 320(RGB)×240 , QVGA | Configuration | RGB Vertical Stripe |
Active Area(mm) | 53.28(W)×71.04(H) mm | Outline(mm) | 76.9(W)×63.9(H) ×3.46(D) mm |
Bezel Opening(mm) | 73.03(W)×55.50(H) mm | Treatment | - |
Luminance | 300 cd/m² (Typ.) | Contrast Ratio | 400:1 (Typ.) (TM) |
View Direction | - | Response Time | 10/15 (Typ.)(Tr/Td) |
Viewing Angle | 60/60/50/55 (Typ.)(CR≥5) | Touch screen | Without |
Voltage Supply | 3.3V (Typ.) |
|
|
Support Color | 16.7M 60% (CIE1931) | Used for | Handled PDA |
Refresh Rate | 60Hz |
|
|
Light Source | 6S1P WLED , 10K hours , Without Driver | Signal Type | Digital RGB (8/24-bit) + SPI, CCIR601/656 , 54 pins , FPC |
Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C | ||
