IPS 4K с ЖК-дисплеем 13 3 дюймов 3840x2160 eDP интерфейс highcolor гамму подсветкой WLED 40 штифтов lcd

General Features

Panel Size

13.3 inch

Panel Type

LCM , IGZO TFT-LCD

Resolution

3840(RGB)×2160   (UHD)

Arrangement

RGB Vertical Stripe

Active Area

293.76 × 165.24 (H×V)

Outline(mm)

299.46 × 186.67 × 2.2 (H×V×D)

Bezel Area(mm)

296.56 × 168.16 (H×V)

Treatment

Glare (Haze 0%), Hard coating (3H)

Luminance

340 (Typ.)(cd/m²)

Contrast Ratio

1400 : 1 (Typ.) (TM)

Viewing Angle

85/85/85/85 (Typ.)(CR≥10)

Work Mode

IPS, Normally Black, Transmissive

Best View on

Symmetry

Response Time

35 (Typ.)(Tr+Td) ms

Color Depth

16.7M   72% (CIE1931)

Backlight

WLED , 15K hours , With LED Driver

Refresh Rate

60 Hz

Touch Screen

Optional

Voltage Supply

3.3V(Typ.)

Application

Notebook Computers etc.

Shape Style

eDP (4 Lanes) , Connector , 40 pins

Max. Ratings

Storage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 50 °C
