Электрический привод XCMG XDE100S

Цена:10 000,00 $ - 500 000,00 $*

Стоимость в USD (на сегодня):Узнать

Количество:

Product Description

XCMG Official XDE100S Electric Drive Sprinkler for sale

1.Adopt AC drive technology to reduce system maintenance workload and improve machine's grade-ability.

2.Possess the functions of dust reduction, firefighting, muck pile flushing, industrial water transmission,etc.

3.Adopt lightweight water tank to improve fuel economy.

4.Adopt new remote point-touch fire water monitor featured with cnovenience and flexibiliity.

5.Adopt advanced antirust treatment to effectively prolong the service life of water tank.

Product Paramenters

Item					Unit	Parameter
Dimension	Overall Truck Length			mm	11480
		Overall Truck Width			mm	6200
		Front Canopy Height			mm	6170
		Wheel base			mm	4900
		Tire center distance	Front	mm	4745
		Tire center distance		Rear	mm	3770
Weight	Gross Vehicle Weight (GVW)			kg	189000
		Payload			kg	100000
		Empty vehicle weight			kg	89000
Weight Distribution	Unload	Front axle	kg	44500 (50%)
	Unload			Rear axle	kg	44500 (50%)
		Loaded	Front axle	kg	62370 (33%)
		Loaded		Rear axle	kg	126630 (67%)
Power Train	Engine			/	MTU16V2000C22 Tierll
		Optional			/	Cummins QSK38 Tierll
		Rated power			kW/rpm	899/1800
		Max. torque			N.m/rpm	5295/1500
		Drive			/	4x2
		Tire			/	30.00R51
Electric Drive System	Transmission Mode			/	XCMG AC electric drive
		Alternator			/	XCMG-A865
		Wheel Motor			/	XCMG-M345
		Reduction Ratio				33.67:1
Driving Performance	Max. vehicle speed			km/h	50
		Min. turning diameter			m	22
		Max.gradeability			%	20
		Min. ground clearance			mm	570
Working Parameter	prinkling vehicle speed			Km/h	5~20
		Centrifugal pump head			m	90
		Water sprinkling volume			L/m2	0.4-1.0
		Sprinkling width			m	15-30
		Maximum range of water monitor			m	60
