Good Power Effective Wind Turbine 96V/120V/240V/380V wind turbine 100 kw

   wind turbine 500 kw



Specification Sheet



Product picture	Model	EN-1000W-L	EN-1500W-L	EN-2000W-L	EN-2500W-L
	Rated power	1000W	1500W	2000W	2500W
	Max power	1200W	1700W	2300W	2800W
	Nominal voltage	48V	48V	48V/96V	48V/96V
	Start-up wind speed	2.5m/s	2.5m/s	2.5m/s	2.5m/s
	Rated wind speed	11m/s	11m/s	11m/s	11m/s
	Survival wind speed	45m/s	45m/s	45m/s	45m/s
	Top net weight	45kg	50kg	55kg	60kg
	Wind wheel diameter	2.9m	3.2m	3.7m	3.7m
	Number of blades	3pcs
	Blades material	Reinforced glass fiber
	Generator	Three phase ac permanent magnet generator
	Controller system	Electromagnetic/Wind wheel yaw
	Speed regulation	The wind Angle automatically
	Working temperature	-40°C~80°C





Product picture	Model	EN-3000W-G	EN-5000W-G	EN-10KW-G
	Rated power	3000W	5000W	10000W
	Max power	3500W	5700W	13000W
	Nominal voltage	48V/96V/120V	96V/120V/ 240V	120V/220V/380V
	Start-up wind speed	2.5m/s	2.5m/s	2.5m/s
	Rated wind speed	11m/s	11m/s	11m/s
	Survival wind speed	45m/s	45m/s	45m/s
	Top net weight	205kg	285kg	400kg
	Wind wheel diameter	5.2m	6.1m	7.8m
	Number of blades	3pcs
	Blades material	Reinforced glass fiber
	Generator	Three phase ac permanent magnet generator
	Controller system	Electromagnetic/Wind wheel yaw
	Speed regulation	The wind Angle automatically
	Working temperature	-40°C~80°C



Product picture	Model	EN-10KW-E	EN-20KW-E	EN-30KW-E	EN-50KW-E	EN-100KW-E
	Rated power	10KW	20KW	30KW	50KW	100KW
	Max power	12KW	23KW	33W	55KW	110KW
	Nominal voltage	120/220V	220/360V	360V	360V	360V
	Start-up wind speed	2.5m/s	2.5m/s	2.5m/s	2.5m/s	2.5m/s
	Rated wind speed	10m/s	10m/s	10m/s	10m/s	10m/s
	Survival wind speed	45m/s	45m/s	45m/s	45m/s	45m/s
	Wind wheel diameter	7.8m	10m	12m	18m	22m
	Number of blades	3pcs
	Blades material	Reinforced glass fiber
	Generator	Three phase ac permanent magnet AC generator
	Controller system	Electronically controlled yaw protection
	Speed regulation	Electronically controlled yaw
	Working temperature	-40°C~80°C
	Lubrication	Grease injection



   wind turbine 500 kw

 wind turbine 500 kw

   wind turbine 500 kw

Just feel free to me for more information.
