Hualong оборудование для работы с камнем HKSS-1400 камнерезные машины горизонтальном и вертикальном положении пилы песчаника латерита кирпич добычи полезных
- Категории: Коммерческой техники >>>
- Поставщик: Fujian,Province,Hualong,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Sandstone Quarry Cutting Machine
HKSS-1400 is suitable for mining the sandstone, limestone and lieterate, cutting into blocks for building.
TECHNICAL DATA for HKSS-1400 | ||||||
Power of Motor | Vertical | Kw | 75 | |||
Horizontal | Kw | 45 | ||||
Rail | Kw | 5.5 | ||||
Main Performance Parameters | Moving speed (forward & backward) | m/min | 10-45 | |||
Max distance of cylinder lifting | mm | 700 | ||||
Max cutting depth | mm | 520 | ||||
Blade | Diameter of the vertical | mm | 1330 | |||
Diameter of the horizontal | mm | 600 | ||||
Thickness | mm | 11.5 | ||||
Brick products quarried:
Main Features
1) The longitudinal cutting relies on the large main column vertical guide rail, the structure of which is simple and strong, straight up and down runs stably.
2) Simple interface, easy to operate. A worker is able to employ it at best after having a try of few hours.
3) Crosscutting with the thick and big swing arm structure, the cutting is stable and fast.
4) Powerful motors with 93% efficiency, tall output and low consumption.
Control Companent
Name: Joystick
Quantity: 5 pcs
It's simply and easy to control the machine up/down, the spindle up/down, left/right, the blade cover open/close..
Main motor
Name: Three-phase asymchronous motor
Brand: XDDJ
Efficiency: 93.1%
Original: China
Domestic famous engines, strong driving force, good efficiency, high economic benefits.
Power Connection & Operation Panel
Brand: Siemens, Schneider, SANCH
Original: China
Quality certificated by CE
Blades
Blades are made of Q460c manganese steel(difficult deformation)+heat treatment,HR up to 52. The cutter heads are made of cemented carbide,hard,wear-resisting,heat-resisting and corrosion resisting.
Q: What is the MOQ?
A: 1 set.
Q: When will you ship my order?
A: Normally 25-35 days after deposit received, If urgent, it can be negotiated further.
Q: What’s the warranty time?
A: One year.
A: 1 set.
Q: When will you ship my order?
A: Normally 25-35 days after deposit received, If urgent, it can be negotiated further.
Q: What’s the warranty time?
A: One year.
