Лидер продаж партиями по 4 оси мульти шпиндели токарный станок с компьютерным числовым программным управлением для лестничные пирила ПВХ

wood lathe

Certificate

CE

Machine material

Cast iron

Max working diameter

300mm

Max working length

2000mm

Rotating motor

Servo motor 3.7KW

Spindle rotating speed

0-3000r/min

Inverter

Best inverter 4.0kw

Drive system

Stepper motors 450C and Yako 2811 drives

Guide rail

Taiwan HIWIN linear square guide rail 25mm

Transmission

Y axis:Rack and pinion,

X and Z axis :Taiwan TBI rolling ball screw

Engraving spindle

3.5kw air cooling

Adjustable bracket in any direction

Control system

DSP 4 axis system

Air pressure

0.6-0.8Mpa

Software compatiliby

Type3/Artcam/Artcut/Ucancam/JDpaint etc.

Command language

G-code

Computer interface

USB

Working voltage

380V, 50/60HZ

Maintainance

Oil lubricating system

Environment temperature

0-45 ℃

Relative humidity

30%-75%

Machine size

2500*1300*1350mm

Machine Weight

1600kgs
