Product Description

CE Certified Industrial -15 Degree To Room Temperature 3L Air Cooled Mini Water Cooling Chiller Wholesale Price


Product Application


Zhengzhou Sykes Low Temperature Cooling Liquid Circulator ( also called Recyclable Chiller or Coolant Circulator or Water Cooling Chiller ) DL-400 is designed for 0.5L ~ 2L small lab scale rotary evaporator. Small footprint can save laboratory space. It is can be placed on the bench or on the floor.

 It is widely applied in low temperature condition for chemical, biological and physical experiments which need to be carried on under low temperature.

Usually, recyclable chiller is used with a lab-scale rotary evaporator and a vacuum pump to form a total system to complete the experiment.

Technical Data


\t
Product
\t
Low Temperature Water Cooling Circulator
\t
Model
\t
DL-400
\t
Capacity of liquid storage tank ( L )
\t
3
\t
Using temperature range (℃)
\t
-15~ Room temperature
\t
Ambient temperature (℃)
\t
≤25
\t
Relative humidity ( % )
\t
≤60
\t
Power Supply
\t
220V±10%V/50Hz or 110V/60Hz
\t

Temperature control
\t
Display mode
\t
LCD Display
\t
Temperature stability (℃)
\t
±2
\t
Temperature sensor
\t
Pt100
\t
Adjustable range of instrument (℃)
\t
±50
\t
Setting mode
\t
Random setting within using temperature range
\t
Safety protection
\t
Delay, overcurrent, overheating
\t
Cooling

capacity

(W)

\t
10℃
\t
1000
\t
0℃
\t
970
\t
-10℃
\t
620
\t
-15℃
\t
510
\t
Refrigerated

unit

\t
Power (W)
\t
606
\t
Current (A)
\t
2.7
\t
Refrigerant
\t
R22, R404A
\t

Circulating pump
\t
Power (W)
\t
100
\t
Flow (L/min)
\t
12
\t
Lift(m)
\t
5~7
\t
External loop interface
\t
Material:304
\t
Liquid
storage
tank

\t
Inner diameter and height (mm)
\t
Ф180*110
\t
Material
\t
1Cr18Ni9Ti
\t
Dimension ( mm )
\t
415×225×497
\t
Weight ( kg )
\t
30

Main Features

1) Compact design with small footprint

2) Air cooled type

3) Large LCD display operation panel

4) The complete closed circulating system can prevent volatilization and pollution of coolant efficiently, and can save resources.


Detailed Images

                        Front


                            Left


                        Right






LCD Operation Panel








Stainless Steel Circulating Liquid Inlet and Outlet


Corollary Equipments

* -15℃ To Room Temperature Water Cooling Chiller DL-400

* 500ml ~ 2L Rotary Evaporator SK-98-1

* Spray Paint Teflon ( PTFE ) Water Circulating Vacuum Pump SHZ-IIIG


* -15℃ To Room Temperature Water Cooling Chiller DL-400

* 1L ~ 5L Short Path Distillation Kit SPD Series

* Spray Paint Teflon ( PTFE ) Water Circulating Vacuum Pump SHZ-IIIG


* -15℃ To Room Temperature Water Cooling Chiller DL-400

* 1L ~ 5L Short Path Distillation Kit SPD Series

* Diaphragm Vacuum Pump MP-201

CE Certificate
