6x4 25000 кг Sinotruck howo 16000L пожарная пена и резервуар для воды машина сухой порошок
- Категории: Emergency Vehicles >>>
- Поставщик: Hubei,Chenyang,Special,Vehicles,Co.,Ltd
Поделиться:
Описание и отзывы
Характеристики
1.Chassis
| Chassis model | ZZ5207N4617E5 |
| Drive Type | 6x4 |
| Whelbase | 460+1350mm |
| Top Speed | 95km/h |
| Engine Type | D10.31-50(GB17691-2005,GB3847-2005)(diesel)(Euro 5) |
| Power | 276kw |
2.Driving room
| Size(L*w*H) | 10075*2500*3650 |
| Structure | Flat head, four door double row cab |
| Seat set | 3+3(three people in the front row (including the driver) and three in the back) |
| Equipment | In addition to the original vehicle equipment, it is equipped with 100W alarm, rotary warning light switch, lever control switch and indicator light |
3.Volume of tank
| Volume | water:14000L,foam:2000L |
| Material | High quality carbon steel plate |
| Structure | Steel plate welded type, internal anti - swash plate |
| Equipment | 2 population hole, with a quick locking and opening device 2 overflow device 2 level indicator 2 outlet, manual control valve |
| Technical requirements | Comply with the relevant provisions of GA39 |
4.Fire pump
| Model | CB10/60 |
| Flow | 60L/s |
| pressure | 1.0Mpa |
| Water diversion time | ≤50s |
| Type of installation | rear-mounted |
5.fire monitor
| Model | PL48 |
| Flow | 48L/s |
| Range | range of water more than 65m,range of foam more than 55m. |
| pressure | 1.0Mpa |
| Turning Angle | The level is greater than 270 degrees, and the pitch is -15 to 45 degrees. |
 |  |
 |  |
