Model | XDT5401THB-(48/5) | HDT5282THB-37/4 | HDT5292THB-38/4 | HDT5210THB(33/5) | |
Pumping system parameters | Theoretical Concrete output | 120m3/h | 120m3/h | 120m3/h | 92m3/h |
Theoretical pumping pressure | 8Mpa | 8Mpa | 8Mpa | 8Mpa | |
Inside Diameter of concrete cylinder | 230mm | 230mm | 230mm | 230mm/200mm | |
Concrete cylinder stroke | 2000mm | 2000mm | 2000mm | 1600mm/1400mm | |
Hydraulic system | Close-type | Close-type | Close-type | Open-type | |
System oil pressure | 32Mpa | 32Mpa | 32Mpa | 32Mpa | |
Inside diameter of conveying pipe | 125mm | 125mm | 125mm | 125mm | |
End hose length | 3000mm | 4000mm | 4000mm | 3000mm | |
Chassis parameters | Chassis model | ZZ5207M5617D1 | --------- | ------ | SINOTRUCK ZZ5215N5113E1 |
Wheelbase | 5600mm | ------- | ------ | 5100mm | |
Driving type | 8*4 | ------ | ----- | 4×2 | |
Engine model | 6WG1-TCG51 | -------- | ------ | WC07.31-50 | |
Engine power | 338km/1800rpm | 294kw/rpm or 279kw/rpm | 294kw/rpm or 279kw/rpm | 228KW/2300rpm | |
Max speed | 80km/h | 80km/h | 80km/h | 92Km/h |
1) The large-diameter and big-flow valve group, small in size and light in weight , is well known for its high response speed and less power loss.
2)The new generation of electronic control system, which adopts an energy-saving control technology, is safe and reliable and enjoys a high maintainability. The fuel consumption during concrete pumping operation is about 0.5L/m3
3) The adoption of fault self-diagnosis system,CAN bus and special controller applications ensures that the operator can get the fault information and solve the problem in time, greatly improving the reliability of the electrical system.
Q:Why do you choose us?
A:we are the manufacturer,with 20 years experience.
Q:What is your Quality Control (QC)?
A:Third Control, ISO,CCC,CE Certificate ,European Certificate.
Q:How to visit your company?
A:Our factory is in YANTAI city, Shandong Province.
Q:which countries did we export?
A: India, Bangladesh, Vietnam, Vietnam, and the Middle East, etc.
Q:Can you customize your products?
A:Yes, we will do the customization by requirement without affecting the quality of the products
Q:How long is the warranty period ?
A:We offer 12 months warranty for the machine (main body) from the date of installation finished.
Q:What's the payment method ?
A:We accept L/C, T/T and D/P payment.
