Product Description
High frequency welding machine for PVC stretch ceiling seaming, it is good design and use high quality electronic parts, we was sold more than 1000sets in Russia and Ukraine, and Turkey market.
Features and Functions:
1. Anti-spark protection system
When HF welding spark occur, the NL5557 high sensitiveness spark start working to protects electric system, cut down high frequency power immediately to protect electronic parts, mould and raw material.
2. Safety device
When the current exceeds its limit, the overload relay functions automatically to protect oscillation tubes and rectifier. Frequency deviation caused by misoperation is also prevented.
3. Strong welding power
High frequency welding machine using a pneumatic, the maximum pressure of foot pedal can reach up to 400KGS so as to meet most operating conditions. The high quality components make these machines work very smoothly and precisely.
4. Easy tuning and special protection circuit
The selectable output power ensured a stable quality of the products for it could reduce the heating time when joining is being carried out.
5. Easily adjustable power switch
High frequency welding machine output power can be adjusted at the tuner according to electrode size and material thickness. In addition, other control devices and special electrical circuits have cut down required welding time considerably to raise the machine productivity.
6. Adjustment for the distance on the machine head
High frequency welding machine adjust the distance on the machine head if practical as the mould's size and height are different.
Characteristics:
1. High sensitivity spark protection circuit, which can effectivelycut off the high current output, suppression of sparks.
2. Pneumatic devices, saving time, duplex, consistent and easy to operate.
3. Square-sype level adjustment, time-saving and easy transfer.
4. Main parts adopts imported components, Taiwan Airtac, Japan Omron, Toshiba and NL-5557.
5. Dual working station, foot pedal control.
6. 27.12 Mhz standard frequency.
7. Foot pedal control, fully imported pneumatic components, stable welding.
8. The machine meet with CE requirement.
9. Machine can be installing two molds, seperated operation.
Features and Functions:
1. Anti-spark protection system
When HF welding spark occur, the NL5557 high sensitiveness spark start working to protects electric system, cut down high frequency power immediately to protect electronic parts, mould and raw material.
2. Safety device
When the current exceeds its limit, the overload relay functions automatically to protect oscillation tubes and rectifier. Frequency deviation caused by misoperation is also prevented.
3. Strong welding power
High frequency welding machine using a pneumatic, the maximum pressure of foot pedal can reach up to 400KGS so as to meet most operating conditions. The high quality components make these machines work very smoothly and precisely.
4. Easy tuning and special protection circuit
The selectable output power ensured a stable quality of the products for it could reduce the heating time when joining is being carried out.
5. Easily adjustable power switch
High frequency welding machine output power can be adjusted at the tuner according to electrode size and material thickness. In addition, other control devices and special electrical circuits have cut down required welding time considerably to raise the machine productivity.
6. Adjustment for the distance on the machine head
High frequency welding machine adjust the distance on the machine head if practical as the mould's size and height are different.
Characteristics:
1. High sensitivity spark protection circuit, which can effectivelycut off the high current output, suppression of sparks.
2. Pneumatic devices, saving time, duplex, consistent and easy to operate.
3. Square-sype level adjustment, time-saving and easy transfer.
4. Main parts adopts imported components, Taiwan Airtac, Japan Omron, Toshiba and NL-5557.
5. Dual working station, foot pedal control.
6. 27.12 Mhz standard frequency.
7. Foot pedal control, fully imported pneumatic components, stable welding.
8. The machine meet with CE requirement.
9. Machine can be installing two molds, seperated operation.
Parameters:
| Model | BM-5000HTA |
| HF Power | 5000W |
| Power supply | 3Phase, 220V/380V/415V/440V |
| Power Input | 7KVA |
| Rectifier | Silicon diode |
| Oscillation tube | Japan Toshiba E3185 |
| Oscillation frequency | 47.12Mhz International Standard |
| Pressure way | Foot / Pneumatic |
| Stroke | 75mm |
| Up board | 160mm*300mm |
| Working plate | 350mm*700mm |
| Machine size | L1710mm*W1140mm*H1550mm |
| Weight | 400kg |
Samples:
