The plastic rope making machine is making strands and ropes together made a new machines.
Plastic rope making machine is suitable to make 3-30mm rope with plastic round yarn, flat yarn, monofilament, cotton, jute, etc.
Suitable for plastic round yarn, flat yarn, monofilament, nylon, polyester, danline, cotton, hemp, monofilament as raw material to produce rope.
Main features
2.Inverter driving, meter counter, Setting meters can be automatically stop,use the second start way, automatically cut off power supply if open the door
3.Adjustable twist
4.Stable performance ,low consumption, little noise, convenient maintenance
Model | Rope diameter | Twisted degree | Twisted orientation | Motor power | Dimension | Capacity |
M33 | 3-8mm | 26-82 | S or Z | 3KW-4 | 4*1.9*1.8m | 0.2-1.2 T |
M44 | 3-12mm | 16-62 | S or Z | 5.5KW-4 | 5*1.9*1.8m | 0.1-1.4 T |
M55 | 6-18mm | 16-62 | S or Z | 7.5KW-4 | 6.86*2*2.1m | 0.6-2.3 T |
M66 | 8-23mm | 16-62 | S or Z | 15KW-4 | 13*2.3*2.1m | 0.4-3.5 T |
M77 | 12-30mm | 16-62 | S or Z | 18KW-4 | 14.8*2.5*2.1m | 0.6-4.6 T |
Laizhou YiBang Machinery Co., Ltd is special plastic wire drawing machine and rope making machine manufacturer, located at North China plastic base - Laizhou City of Shandong Province .
The company is committed to the rope,wire,net,etc,machinery,service and training.
Main Products: PP/PE/PET/NYLON monofilament machine, plastic wire drawing machine, 3-30mm rope making machine, pp rope making machine, pp plastic twine rope machine, plastic flat yarn making machine, twisting machine, thread ball making machine, spooling machine and rope coiler machine and winding equipment etc.
